Parameter Description
13-52 SL Controller Action
Array [20]
Option:
[13] Select preset
ref 3
3 3
[14] Select preset
ref 4
[15] Select preset
ref 5
[16] Select preset
ref 6
[17] Select preset
ref 7
[18] Select ramp 1
[19] Select ramp 2
[22] Run
[23] Run reverse
[24] Stop
[26] DC Brake
[27] Coast
[28] Freeze output
[29] Start timer 0
[30] Start timer 1
[31] Start timer 2
[32] Set digital out
A low
[33] Set digital out
B low
[34] Set digital out
C low
[35] Set digital out
D low
[36] Set digital out
E low
[37] Set digital out
F low
104
®
VLT Refrigeration Drive FC 103
Function:
Selects preset reference 3.
Selects preset reference 4.
Selects preset reference 5.
Selects preset reference 6.
Selects preset reference 7. If the active
preset reference is changed, it merges
with other preset reference commands
coming from either the digital inputs or
via a fieldbus.
Selects ramp 1.
Selects ramp 2.
Issues a start command to the frequency
converter.
Issues a start reverse command to the
frequency converter.
Issues a stop command to the frequency
converter.
Issues a DC stop command to the
frequency converter.
The frequency converter coasts
immediately. All stop commands including
the coast command stop the SLC.
Freezes the output frequency of the
frequency converter.
Starts timer 0, see parameter 13-20 SL
Controller Timer for further description.
Starts timer 1, see parameter 13-20 SL
Controller Timer for further description.
Starts timer 2, see parameter 13-20 SL
Controller Timer for further description.
Any output with digital output 1 selected
is low (off).
Any output with digital output 2 selected
is low (off).
Any output with digital output 3 selected
is low (off).
Any output with digital output 4 selected
is low (off).
Any output with digital output 5 selected
is low (off).
Any output with digital output 6 selected
is low (off).
Danfoss A/S © 05/2016 All rights reserved.
13-52 SL Controller Action
Array [20]
Option: Function:
[38] Set digital out Any output with digital output 1 selected
A high is high (closed).
[39] Set digital out Any output with digital output 2 selected
B high is high (closed).
[40] Set digital out Any output with digital output 3 selected
C high is high (closed).
[41] Set digital out Any output with digital output 4 selected
D high is high (closed).
[42] Set digital out Any output with digital output 5 selected
E high is high (closed).
[43] Set digital out Any output with digital output 6 selected
F high is high (closed).
[50] Night Action
[51] Day Action
[60] Reset Counter Resets counter A to 0.
A
[61] Reset Counter B Resets counter B to 0.
[70] Start Timer 3 Starts timer 3, see parameter 13-20 SL
Controller Timer for further description.
[71] Start Timer 4 Starts timer 4, see parameter 13-20 SL
Controller Timer for further description.
[72] Start Timer 5 Starts timer 5, see parameter 13-20 SL
Controller Timer for further description.
[73] Start Timer 6 Starts timer 6, see parameter 13-20 SL
Controller Timer for further description.
[74] Start Timer 7 Starts timer 7, see parameter 13-20 SL
Controller Timer for further description.
[80] Sleep Mode Starts the sleep mode.
3.11.7 13-9* User-defined Alerts and
Readouts
Parameters in this group allow the configuration of
application-specific messages, warnings, and alarms.
Use the following parameters to configure the frequency
converter to show a message and perform an action when
a specific event occurs:
•
Parameter 13-90 Alert Trigger – the event that
triggers the user-defined action and message.
•
Parameter 13-91 Alert Action – the action that the
frequency converter performs when the event
defined in parameter 13-90 Alert Trigger occurs.
•
Parameter 13-92 Alert Text – the text that the
frequency converter shows in the display when
the event defined in parameter 13-90 Alert Trigger
occurs.
