For example, consider the following use case:
If there is an active signal on digital input 32, the
frequency converter shows the message Valve 5 open in
the display and ramps down to a stop.
To achieve this configuration, make the following settings:
•
Parameter 13-90 Alert Trigger = [37] Digital input
DI32.
•
Parameter 13-91 Alert Action = [5] Stop & warning.
•
Parameter 13-92 Alert Text = Valve 5 open.
13-90 Alert Trigger
Array [10]
Select the event that triggers the user-defined action and
message.
Option:
[0] False
*
[1] True
[18] Reversing
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
13-91 Alert Action
Array [10]
Select the action that the frequency converter performs when
the event defined in parameter 13-90 Alert Trigger occurs.
Option:
[0] Info
*
[1] Warning
[2] Freeze output
[3] Freeze output & warn
[4] Stop
MG16H202
Programming Guide
13-91 Alert Action
Array [10]
Select the action that the frequency converter performs when
the event defined in parameter 13-90 Alert Trigger occurs.
Option:
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[12]
Function:
[13]
[14]
13-92 Alert Text
Array [10]
Enter the text that the frequency converter shows in the display
when the event defined in parameter 13-90 Alert Trigger occurs.
Range:
Size related
13-97 Alert Alarm Word
Range:
0 [0 - 4294967295] Shows the alarm word of a user-defined
*
13-98 Alert Warning Word
Range:
0 [0 - 4294967295] Shows the warning word of a user-
*
13-99 Alert Status Word
Range:
0 [0 - 4294967295] Shows the status word of a user-defined
*
Function:
Danfoss A/S © 05/2016 All rights reserved.
Stop & warning
Jogging
Jogging & warning
Max speed
Max speed & warn
Stop and trip
Stop and trip w manual
reset
Trip
Trip w manual reset
Trip Lock
Function:
[0 - 20]
*
Function:
alarm in hex code.
Function:
defined alarm in hex code.
Function:
alarm in hex code.
Function:
3 3
