5-23 Terminal X46/7 Digital Input
This parameter is related to the digital input on VLT
Relay Card MCB 113. The parameter contains all options and
functions listed in parameter group 5-1* Digital Inputs except for
option [32] Pulse input.
3 3
5-24 Terminal X46/9 Digital Input
This parameter is related to the digital input on VLT
Relay Card MCB 113. The parameter contains all options and
functions listed in parameter group 5-1* Digital Inputs except for
option [32] Pulse input.
5-25 Terminal X46/11 Digital Input
This parameter is related to the digital input on VLT
Relay Card MCB 113. The parameter contains all options and
functions listed in parameter group 5-1* Digital Inputs except for
option [32] Pulse input.
5-26 Terminal X46/13 Digital Input
This parameter is related to the digital input on VLT
Relay Card MCB 113. The parameter contains all options and
functions listed in parameter group 5-1* Digital Inputs except for
option [32] Pulse input.
3.7.3 5-3* Digital Outputs
Parameters for configuring the output functions for the
output terminals. The 2 solid-state digital outputs are
common for terminals 27 and 29. Set the I/O function for
terminal 27 in parameter 5-01 Terminal 27 Mode and set the
I/O function for terminal 29 in parameter 5-02 Terminal 29
Mode.
NOTICE
These parameters cannot be adjusted while the motor is
running.
[0] No operation
[1] Control ready
[2] Drive ready
[3] Drive ready /
remote
control
[4] Stand-by / no
warning
[5] Running
[6] Running / no
warning
70
®
VLT Refrigeration Drive FC 103
®
Extended
®
Extended
®
Extended
®
Extended
The digital outputs can be programmed
with these functions:
Default for all digital outputs and relay
outputs.
The control board receives supply voltage.
The frequency converter is ready for
operation and applies a supply signal on
the control board.
The frequency converter is ready for
operation and is in auto-on mode.
The frequency converter is ready for
operation. No start or stop command is
given (start/disable). There are no
warnings.
The motor is running.
The output speed is higher than the speed
set in parameter 1-81 Min Speed for
Danfoss A/S © 05/2016 All rights reserved.
Function at Stop [RPM]. The motor is
running, and there are no warnings.
[8] Run on The motor is running at reference speed.
reference / no
warning
[9] Alarm An alarm activates the output. There are
no warnings.
[10] Alarm or An alarm or a warning activates the
warning output.
[11] At torque The torque limit set in
limit parameter 4-16 Torque Limit Motor Mode or
parameter 4-13 Motor Speed High Limit
[RPM] has been exceeded.
[12] Out of current The motor current is outside the range set
range in parameter 4-18 Current Limit.
[13] Below current, The motor current is lower than set in
low parameter 4-50 Warning Current Low.
[14] Above The motor current is higher than set in
current, high parameter 4-51 Warning Current High.
[15] Out of speed The output speed is outside the range set
range in parameter 4-52 Warning Speed Low and
parameter 4-53 Warning Speed High.
[16] Below speed, The output speed is lower than the setting
low in parameter 4-52 Warning Speed Low.
[17] Above speed, The output speed is higher than the
high setting in parameter 4-53 Warning Speed
High.
[18] Out of The feedback is outside the range set in
feedback parameter 4-56 Warning Feedback Low and
range parameter 4-57 Warning Feedback High.
[19] Below The feedback is below the limit set in
feedback low parameter 4-56 Warning Feedback Low.
[20] Above The feedback is above the limit set in
feedback high parameter 4-57 Warning Feedback High.
[21] Thermal The thermal warning turns on when the
warning temperature exceeds the limit in the
motor, the frequency converter, the brake
resistor, or the thermistor.
[25] Reverse The motor is running (or is ready to run)
clockwise when there is a logic 0 signal
and counterclockwise when there is a logic
1 signal. The output changes as soon as
the reversing signal is applied.
[26] Bus OK Active communication (no timeout) via the
serial communication port.
[27] Torque limit Use this option to perform a coasting stop
and stop and in torque limit condition. If the
frequency converter has received a stop
signal and is at the torque limit, the signal
is logic 0.
[28] Brake, no The brake is active and there are no
warning warnings.
[29] Brake ready, The brake is ready for operation and there
no fault are no faults.
MG16H202
