Danfoss VLT Refrigeration Drive FC 103 Programming Manual page 103

Parameter Description
13-41 Logic Rule Operator 1
Array [6]
Option: Function:
Parameter numbers in square brackets stand
for the boolean inputs of parameters in
chapter 3.11 Parameters: 13-** Smart Logic.
[0] DISABLED Ignores:
•
Parameter 13-42 Logic Rule Boolean 2.
•
Parameter 13-43 Logic Rule Operator 2.
•
Parameter 13-44 Logic Rule Boolean 3.
[1] AND Evaluates the expression [13-40] AND [13-42].
[2] OR Evaluates the expression [13-40] OR [13-42].
[3] AND NOT Evaluates the expression [13-40] AND NOT
[13-42].
[4] OR NOT Evaluates the expression [13-40] OR NOT
[13-42].
[5] NOT AND Evaluates the expression NOT [13-40] AND
[13-42].
[6] NOT OR Evaluates the expression NOT [13-40] OR
[13-42].
[7] NOT AND Evaluates the expression NOT [13-40] AND NOT
NOT [13-42].
[8] NOT OR Evaluates the expression NOT [13-40] OR NOT
NOT [13-42].
13-42 Logic Rule Boolean 2
Array [6]
Option: Function:
Select the 2
input for the selected logic rule.
See parameter 13-40 Logic Rule
Boolean 1 for further descriptions of
options and their functions.
[0] False
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current Limit
[7] Out of current range
[8] Below I low
[9] Above I high
[10] Out of speed range
[11] Below speed low
[12] Above speed high
[13] Out of feedb. range
[14] Below feedb. low
[15] Above feedb. high
[16] Thermal warning
MG16H202
Programming Guide
nd
boolean (true or false)
Danfoss A/S © 05/2016 All rights reserved.
13-42 Logic Rule Boolean 2
Array [6]
Option: Function:
[17] Mains out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[39] Start command
[40] Drive stopped
[41] Reset Trip
[42] Auto Reset Trip
[43] OK Key
[44] Reset Key
[45] Left Key
[46] Right Key
[47] Up Key
[48] Down Key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[80] No Flow
[81] Dry Pump
[82] End of Curve
[83] Broken Belt
