13-00 SL Controller Mode
Option: Function:
[0] Off Disables the smart logic controller.
[1] On Enables the smart logic controller.
13-01 Start Event
Option: Function:
Select the boolean (true or false) input
to activate smart logic control.
[0] False Enters the fixed value of false in the
logic rule.
[1] True Enters the fixed value true in the logic
rule.
[2] Running See parameter group 5-3* Digital Outputs
for further description.
[3] In range See parameter group 5-3* Digital Outputs
for further description.
[4] On reference See parameter group 5-3* Digital Outputs
for further description.
[5] Torque limit See parameter group 5-3* Digital Outputs
for further description.
[6] Current Limit See parameter group 5-3* Digital Outputs
for further description.
[7] Out of current See parameter group 5-3* Digital Outputs
range for further description.
[8] Below I low See parameter group 5-3* Digital Outputs
for further description.
[9] Above I high See parameter group 5-3* Digital Outputs
for further description.
[10] Out of speed
range
[11] Below speed low See parameter group 5-3* Digital Outputs
for further description.
[12] Above speed See parameter group 5-3* Digital Outputs
high for further description.
[13] Out of feedb.
range
[14] Below feedb. low
[15] Above feedb.
high
[16] Thermal warning See parameter group 5-3* Digital Outputs
for further description.
[17] Mains out of See parameter group 5-3* Digital Outputs
range for further description.
[18] Reversing See parameter group 5-3* Digital Outputs
for further description.
[19] Warning See parameter group 5-3* Digital Outputs
for further description.
MG16H202
Programming Guide
13-01 Start Event
Option:
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[33] Digital input DI18 Use the value of DI18 in the logic rule
[34] Digital input DI19 Use the value of DI19 in the logic rule
[35] Digital input DI27 Use the value of DI27 in the logic rule
[36] Digital input DI29 Use the value of DI29 in the logic rule
[37] Digital input DI32 Use the value of DI32 in the logic rule
[38] Digital input DI33 Use the value of DI33 in the logic rule
[39] Start command
[40] Drive stopped
[41] Reset Trip
[42] Auto Reset Trip
[43] OK Key
[44] Reset Key
Danfoss A/S © 05/2016 All rights reserved.
Function:
See parameter group 5-3* Digital Outputs
for further description.
See parameter group 5-3* Digital Outputs
for further description.
Use the result of comparator 0 in the
logic rule.
Use the result of comparator 1 in the
logic rule.
Use the result of comparator 2 in the
logic rule.
Use the result of comparator 3 in the
logic rule.
Use the result of logic rule 0 in the logic
rule.
Use the result of logic rule 1 in the logic
rule.
Use the result of logic rule 2 in the logic
rule.
Use the result of logic rule 3 in the logic
rule.
(High = true).
(High = true).
(High = true).
(High = true).
(High = true).
(High = true).
This event is true if the frequency
converter is started (either via digital
input, fieldbus, or other).
This event is true if the frequency
converter is stopped or coasted (either
via digital input, fieldbus, or other).
This event is true if the frequency
converter is tripped (but not trip-locked)
and [Reset] is pressed.
This event is true if the frequency
converter is tripped (but not trip-locked)
and an automatic reset is issued.
This event is true if [OK] is pressed.
This event is true if [Reset] is pressed.
