Parameter Description
5-66 Terminal X30/6 Pulse Output Variable
Select the variable for readout on terminal X30/6.
This parameter is active when VLT
is installed in the frequency converter.
Same options and functions as parameter group 5-6* Pulse
Outputs.
Option:
[45] Bus ctrl.
[48] Bus ctrl., timeout
[100] Output frequency
[101] Reference
[102] Feedback
[103] Motor Current
[104] Torque rel to limit
[105] Torq relate to rated
[106] Power
[107] Speed
[108] Torque
[109] Max Out Freq
[113] Ext. Closed Loop 1
[114] Ext. Closed Loop 2
[115] Ext. Closed Loop 3
5-68 Pulse Output Max Freq #X30/6
Range: Function:
NOTICE
5000 [0 -
Hz 32000 Hz]
*
This parameter cannot be adjusted
while the motor is running.
Select the maximum frequency on terminal
X30/6 referring to the output variable in
parameter 5-66 Terminal X30/6 Pulse Output
Variable.
This parameter is active when VLT
Purpose I/O MCB 101 is installed in the
frequency converter.
3.7.7 5-8* I/O Options
5-80 AHF Cap Reconnect Delay
Range: Function:
25 s [1 - 120 Guarantees a minimum off-time for the
*
s] capacitors. The timer starts once the AHF
capacitor disconnects and has to expire before
the output is allowed to be on again. It only
turns on again if the frequency converter
power is 20–30%.
MG16H202
Programming Guide
®
General Purpose I/O MCB 101
Function:
®
General
Danfoss A/S © 05/2016 All rights reserved.
3.7.8 5-9* Bus-Controlled
This parameter group selects digital and relay outputs via a
fieldbus setting.
5-90 Digital & Relay Bus Control
Range: Function:
0 [0 - This parameter holds the state of the digital
*
2147483647] outputs and relays that are controlled by
bus.
A logical 1 indicates that the output is high
or active.
A logical 0 indicates that the output is low
or inactive.
Bit 0 CC digital output, terminal 27
Bit 1 CC digital output, terminal 29
Bit 2 GPIO digital output, terminal X
30/6
Bit 3 GPIO digital output, terminal X
30/7
Bit 4 CC relay 1 output terminal
Bit 5 CC relay 2 output terminal
Bit 6 Option B relay 1 output terminal
Bit 7 Option B relay 2 output terminal
Bit 8 Option B relay 3 output terminal
Bit 9– Reserved for future terminals
15
Bit 16 Option C relay 1 output terminal
Bit 17 Option C relay 2 output terminal
Bit 18 Option C relay 3 output terminal
Bit 19 Option C relay 4 output terminal
Bit 20 Option C relay 5 output terminal
Bit 21 Option C relay 6 output terminal
Bit 22 Option C relay 7 output terminal
Bit 23 Option C relay 8 output terminal
Bit 24– Reserved for future terminals
31
Table 3.13 Digital Output Bits
5-93 Pulse Out #27 Bus Control
Range: Function:
0 % [0 - 100 %] Contains the frequency to apply to the
*
digital output terminal 27 when it is
configured as bus-controlled.
5-94 Pulse Out #27 Timeout Preset
Range: Function:
0 % [0 - 100 %] Contains the frequency to apply to the
*
digital output terminal 27 when it is
configured as bus-controlled timeout, and
timeout is detected.
