Parameter Description
up while running is required. However, for complex
applications, using the full flexibility of the multiple set-
ups, programming parameter 0-12 This Set-up Linked to may
be required. Using parameter 0-11 Programming Set-up, it is
possible to edit parameters within any of the set-ups while
continuing the frequency converter operation in its active
3 3
set-up which can be a different set-up to the one being
edited. Using parameter 0-51 Set-up Copy, it is possible to
copy parameter settings between the set-ups to enable
quicker commissioning if similar parameter settings are
required in different set-ups.
0-10 Active Set-up
Option:
[0] Factory
setup
[1] Set-up 1
*
[2] Set-up 2
[3] Set-up 3
[4] Set-up 4
[9] Multi Set-
up
0-11 Programming Set-up
Option:
[0] Factory
setup
26
VLT
Function:
Select the set-up in which the frequency
converter is to operate.
Use parameter 0-51 Set-up Copy to copy a set-up
to 1 or all other set-ups. To avoid conflicting
settings of the same parameter within 2
different set-ups, link the set-ups using
parameter 0-12 This Set-up Linked to. Stop the
frequency converter before switching between
set-ups where parameters marked not
changeable during operation have different
values.
Parameters which are not changeable during
operation are marked FALSE in
chapter 4 Parameter Lists.
Cannot be changed. It contains the Danfoss
data set, and can be used as a data source
when returning the other set-ups to a known
state.
[1] Set-up 1 to [4] Set-up 4 are the 4 parameter
set-ups within which all parameters can be
programmed.
Is used for remote set-up selections using digital
inputs and the serial communication port. This
set-up uses the settings from
parameter 0-12 This Set-up Linked to.
Function:
Select the set-up to be edited (that is
programmed) during operation; either the
active set-up or 1 of the inactive set-ups. The
set-up number being edited is shown in the
LCP in brackets.
Cannot be edited, but it is useful as a data
source to return the other set-ups to a known
state.
Danfoss A/S © 05/2016 All rights reserved.
®
Refrigeration Drive FC 103
0-11 Programming Set-up
Option:
[1] Set-up 1
[2] Set-up 2
[3] Set-up 3
[4] Set-up 4
[9] Active Set-
*
up
0-12 This Set-up Linked to
Option:
Function:
[1] Set-up 1 to [4] Set-up 4 can be edited freely
during operation, independently of the active
set-up.
The set-up in which the frequency converter is
operating can be edited during operation.
Editing parameters in the selected set-up
would normally be done from the LCP, but it is
also possible from any of the serial communi-
cation ports.
Function:
Use this parameter only if a change of set-ups
is required while the motor is running. This
parameter ensures that parameters which are
not changeable during operation have the
same setting in all relevant set-ups.
To enable conflict-free changes from 1 set-up to
another while the frequency converter is
running, link set-ups containing parameters
which are not changeable during operation.
The link ensures synchronizing of the not
changeable during operation parameter values
when moving from 1 set-up to another during
operation. Not changeable during operation
parameters can be identified by the label FALSE
in the parameter lists in chapter 4 Parameter
Lists.
The parameter 0-12 This Set-up Linked to feature
is used when [9] Multi set-up in
parameter 0-10 Active Set-up is selected. Use [9]
Multi set-up to move from 1 set-up to another
during operation while the motor runs.
For example:
Use [9] Multi set-up to shift from set-up 1 to set-
up 2 while the motor runs. Program parameters
in set-up 1 first, then ensure that set-up 1 and
set-up 2 are synchronized (or linked).
Synchronization can be performed in 2 ways:
•
Change the edit set-up to [2] Set-up 2
in parameter 0-11 Programming Set-up
and set parameter 0-12 This Set-up
Linked to to [1] Set-up 1. This starts the
linking (synchronizing) process.
