Parameter Description
0-20 Display Line 1.1 Small
Option:
[1834] Analog Out
X42/9 [V]
3 3
[1835] Analog Out
X42/11 [V]
[1857] Air Pressure to
Flow Air Flow
[1860] Digital Input 2
[1870] Mains Voltage
[1871] Mains
Frequency
[1872] Mains Imbalance
[1875] Rectifier DC Volt.
[2117] Ext. 1 Reference
[Unit]
[2118] Ext. 1 Feedback
[Unit]
[2119] Ext. 1 Output
[%]
[2137] Ext. 2 Reference
[Unit]
[2138] Ext. 2 Feedback
[Unit]
[2139] Ext. 2 Output
[%]
[2157] Ext. 3 Reference
[Unit]
[2158] Ext. 3 Feedback
[Unit]
[2159] Ext. 3 Output
[%]
[2230] No-Flow Power
[2316] Maintenance
Text
[2580] Pack Status
[2581] Compressor
Status
[2587] Inverse Interlock
[2588] Pack capacity
[%]
[2827] Discharge
Temperature
[3038] Pressure 1
[3048] Pressure 2
[9920] Fan Ctrl deltaT
30
®
VLT Refrigeration Drive FC 103
Function:
Shows the value of the signal applied
to terminal X42/9 on the analog I/O
card.
Shows the value of the signal applied
to terminal X42/11 on the analog I/O
card.
The value of the reference for extended
closed-loop controller 1.
The value of the feedback signal for
extended closed-loop controller 1.
The value of the output from extended
closed-loop controller 1.
The value of the reference for extended
closed-loop controller 2.
The value of the feedback signal for
extended closed-loop controller 2.
The value of the output from extended
closed-loop controller 2.
The value of the reference for extended
closed-loop controller 3.
The value of the feedback signal for
extended closed-loop controller 3.
The value of the output from extended
closed-loop controller 3.
The calculated no-flow power for the
actual operating speed.
Status for the operation of the pack
controller.
Status for the operation of each
individual compressor controlled by the
pack controller.
Danfoss A/S © 05/2016 All rights reserved.
0-20 Display Line 1.1 Small
Option: Function:
[9921] Fan Ctrl Tmean
[9922] Fan Ctrl NTC
Cmd
[9923] Fan Ctrl i-term
[9924] Rectifier Current
[9952] PC Debug 0
[9953] PC Debug 1
[9954] PC Debug 2
[9961] FPC Debug 0
[9962] FPC Debug 1
[9963] FPC Debug 2
[9964] FPC Debug 3
[9965] FPC Debug 4
0-21 Display Line 1.2 Small
Option: Function:
Application Select a variable for display in line 1, middle
dependent position. The options are the same as listed
for parameter 0-20 Display Line 1.1 Small.
0-22 Display Line 1.3 Small
Option: Function:
Application Select a variable for display in line 1, right
dependent position.
The options are the same as listed for
parameter 0-20 Display Line 1.1 Small.
0-23 Display Line 2 Large
Option: Function:
Application Select a variable for display in line 2.
dependent The options are the same as listed for
parameter 0-20 Display Line 1.1 Small.
0-24 Display Line 3 Large
Option: Function:
Application Select a variable for display in line 3.
dependent The options are the same as listed for
parameter 0-20 Display Line 1.1 Small.
