Parameter Lists
Param- Parameter description
eter #
6-70 Terminal X45/1 Output
6-71 Terminal X45/1 Min. Scale
6-72 Terminal X45/1 Max. Scale
6-73 Terminal X45/1 Bus Control
Terminal X45/1 Output Timeout
6-74 Preset
4 4
6-8* Analog Output X45/3
6-80 Terminal X45/3 Output
6-81 Terminal X45/3 Min. Scale
6-82 Terminal X45/3 Max. Scale
6-83 Terminal X45/3 Bus Control
Terminal X45/3 Output Timeout
6-84 Preset

4.1.9 8-** Communication and Options

Param- Parameter description
eter #
8-0* General Settings
8-01 Control Site
8-02 Control Source
8-03 Control Timeout Time
8-04 Control Timeout Function
8-05 End-of-Timeout Function
8-06 Reset Control Timeout
8-07 Diagnosis Trigger
8-1* Control Settings
8-10 Control Profile
8-13 Configurable Status Word STW
8-16 Store Data Values
8-3* FC Port Settings
8-30 Protocol
8-31 Address
8-32 Baud Rate
8-33 Parity / Stop Bits
8-35 Minimum Response Delay
8-36 Maximum Response Delay
8-37 Maximum Inter-Char Delay
8-4* Adv. Protocol Set.
8-40 Telegram Selection
8-42 PCD Write Configuration
8-43 PCD Read Configuration
8-45 BTM Transaction Command
8-46 BTM Transaction Status
8-47 BTM Timeout
8-5* Digital/Bus
8-50 Coasting Select
8-52 DC Brake Select
8-53 Start Select
8-54 Reversing Select
204
®
VLT Refrigeration Drive FC 103
Default value 4 set-up
[0] No operation All set-ups
0 % All set-ups
100 % All set-ups
0 % All set-ups
0 % 1 set-up
[0] No operation All set-ups
0 % All set-ups
100 % All set-ups
0 % All set-ups
0 % 1 set-up
Default value 4 set-up
[0] Digital and
ctrl.word All set-ups
ExpressionLimit All set-ups
ExpressionLimit 1 set-up
[0] Off 1 set-up
[1] Resume set-up 1 set-up
[0] Do not reset All set-ups
[0] Disable 2 set-ups
[0] FC profile All set-ups
[1] Profile Default All set-ups
[0] Off All set-ups
[0] FC 1 set-up
ExpressionLimit 1 set-up
ExpressionLimit 1 set-up
ExpressionLimit 1 set-up
10 ms 1 set-up
ExpressionLimit 1 set-up
ExpressionLimit 1 set-up
[1] Standard
telegram 1 2 set-ups
ExpressionLimit 2 set-ups
ExpressionLimit 2 set-ups
[0] Off All set-ups
[0] Off All set-ups
60 s 1 set-up
[3] Logic OR All set-ups
ExpressionLimit All set-ups
[3] Logic OR All set-ups
[0] Digital input All set-ups
Danfoss A/S © 05/2016 All rights reserved.
Change during Conversion
operation index
TRUE -
TRUE -2
TRUE -2
TRUE -2
TRUE -2
TRUE -
TRUE -2
TRUE -2
TRUE -2
TRUE -2
Change during Conversion
operation index
TRUE -
TRUE -
TRUE -1
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE 0
TRUE -
TRUE -
TRUE -3
TRUE -3
TRUE -5
TRUE -
TRUE -
TRUE -
FALSE -
TRUE -
FALSE 0
TRUE -
TRUE -
TRUE -
TRUE -
Type
Uint8
Int16
Int16
N2
Uint16
Uint8
Int16
Int16
N2
Uint16
Type
Uint8
Uint8
Uint32
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint16
Uint16
Uint16
Uint8
Uint16
Uint16
Uint8
Uint8
Uint16
Uint8
Uint8
Uint8
Uint8
MG16H202
