Parameter Description
0-30 Custom Readout Unit
Option:
[121] gal/s
[122] gal/min
[123] gal/h
3 3
[124] CFM
[125] ft³/s
[126] ft³/min
[127] ft³/h
[130] lb/s
[131] lb/min
[132] lb/h
[140] ft/s
[141] ft/min
[145] ft
[160] °F
[170] psi
[171] lb/in²
[172] in WG
[173] ft WG
[180] HP
0-31 Custom Readout Min Value
Range:
Size [ 0 - 0
related CustomRea-
*
doutUnit]
0-32 Custom Readout Max Value
Range:
100 Custom-
ReadoutUnit
*
0-37 Display Text 1
Range: Function:
0 [0 - In this parameter, it is possible to write an individual
*
25] text string to be shown in the LCP or to be read via
serial communication.
To show the text permanently, select [37] Display Text
1 in 1 of the following parameters:
32
VLT
Function:
Function:
This parameter allows selection of
the minimum value of the custom-
defined readout (occurs at zero
speed). It is only possible to select a
value different from 0 when selecting
a linear unit in
parameter 0-30 Custom Readout Unit.
For quadratic and cubic units the
minimum value is 0.
Function:
[ par. 0-31 - This parameter sets the
999999.99 maximum value to be shown
CustomRea- when the speed of the motor
doutUnit] has reached the set value for
parameter 4-13 Motor Speed High
Limit [RPM] or
parameter 4-14 Motor Speed High
Limit [Hz] (depends on setting in
parameter 0-02 Motor Speed
Unit).
Danfoss A/S © 05/2016 All rights reserved.
®
Refrigeration Drive FC 103
0-37 Display Text 1
Range:
0-38 Display Text 2
Range:
0 [0 -
*
25]
0-39 Display Text 3
Range:
0 [0 -
*
25]
Function:
•
Parameter 0-20 Display Line 1.1 Small.
•
Parameter 0-21 Display Line 1.2 Small.
•
Parameter 0-22 Display Line 1.3 Small.
•
Parameter 0-23 Display Line 2 Large.
•
Parameter 0-24 Display Line 3 Large.
•
Parameter 0-37 Display Text 1.
Changing parameter 12-08 Host Name changes
parameter 0-37 Display Text 1 - but not vice versa.
Function:
In this parameter, it is possible to write an individual
text string to show in the LCP or to be read via serial
communication.
To show the text permanently, select [38] Display Text
2 in:
•
Parameter 0-20 Display Line 1.1 Small.
•
Parameter 0-21 Display Line 1.2 Small.
•
Parameter 0-22 Display Line 1.3 Small.
•
Parameter 0-23 Display Line 2 Large.
•
Parameter 0-24 Display Line 3 Large.
▲ ▼
Press [ ] or [ ] to change a character. Press [
▶
[ ] to move the cursor. When a character is
highlighted by the cursor, this character can be
changed. A character can be inserted by placing the
cursor between 2 characters and pressing [
Function:
In this parameter, it is possible to write an individual
text string to show in the LCP or to be read via serial
communication. To show the text permanently, select
display text 3 in parameter 0-20 Display Line 1.1 Small,
parameter 0-21 Display Line 1.2 Small,
parameter 0-22 Display Line 1.3 Small,
parameter 0-23 Display Line 2 Large, or
parameter 0-24 Display Line 3 Large. Press [
◀
to change a character. Press [ ] and [
cursor. When a character is highlighted by the cursor,
this character can be changed. A character can be
inserted by placing the cursor between 2 characters
▲ ▼
and pressing [ ] or [ ].
◀
] and
▲ ▼
] or [ ].
▲ ▼
] or [ ]
▶
] to move the
