How to Program

2.1.5 Function Set-ups

The function set-up provides quick and easy access to all
parameters required for most refrigiration applications
including:
•
Most VAV and CAV supply and return fans.
•
Cooling tower fans.
•
Primary pumps.
•
Secondary pumps.
•
Condenser water pumps.
•
Other pump, fan, and compressor applications.
How to access Function Set-up - example
1. Turn on the frequency converter (yellow LED
lights).
Status
28.8%
Auto Remote Running
Illustration 2.15 Frequency Converter Turned On
2. Press [Quick Menus].
13.7%
Quick Menus
Q1 My Personal Menu
Q2 Quick Setup
Q3 Function Setups
Q5 Changes Made
Illustration 2.16 Quick Menu Selected
▲ ▼
3.
Press [ ] and [ ] to scroll down to Function Set-
ups. Press [OK].
69.3%
Quick Menus
Q1 My Personal Menu
Q2 Quick Setup
Q3 Function Setups
Q5 Changes Made
Illustration 2.17 Scrolling to Function Set-up
MG16H202
Programming Guide
1 (1)
2.63kW
5.66A
14.4Hz
0kWh
13.0A 1(1)
5.20A 1(1)
Danfoss A/S © 05/2016 All rights reserved.
4. Function Set-ups options appear. Select Q3-1
General Settings. Press [OK].
28.4%
Function Setups
Q3-1 General Settings
Q3-2 Open Loop Settings
Q3-3 Closed Loop Settings
Q3-4 Application Settings
Illustration 2.18 Function Set-ups Options
▲ ▼
5.
Press [ ] and [ ] to scroll down to Q3-11 Analog
Outputs. Press [OK].
26.0%
General Settings
Q3 - 10 Adv. Motor Settings
Q3 - 11 Analog Output
Q3 - 12 Clock Settings
Q3 - 13 Display Settings
Illustration 2.19 General Settings Options
6. Select parameter 6-50 Terminal 42 Output. Press
[OK].
26.3%
Analog Output
6 - 50 Terminal 42 Output
(100) Output frequency
Illustration 2.20 Parameter 6-50 Terminal 42 Output Selected
▲ ▼
7.
Press [ ] and [ ] to select between the different
options. Press [OK].
43.4%
Analog Output
6-50 Terminal 42 Output
Speed
[107]
Illustration 2.21 Setting a Parameter
2
2.05A 1(1)
Q3
7.14A 1(1)
Q3-1
5.82A 1(1)
03.11
1(1)
7.99A
Q3-11
