Parameter Description
18-33 Analog Out X42/7 [V]
Range:
0 [0 - 30] Readout of the value of the signal applied to
*
3 3
18-34 Analog Out X42/9 [V]
Range:
0 [0 - 30] Readout of the value of the signal applied to
*
18-35 Analog Out X42/11 [V]
Range:
0 [0 - 30] Readout of the value of the signal applied to
*
18-57 Air Pressure to Flow Air Flow
Shows the air flow calculated using the measured pressure
difference.
Range:
0 AirPresToFlowUnit
3.15.3 18-6* Inputs & Outputs 2
This group contains information about digital and analog
I/O ports.
18-60 Digital Input 2
Range:
0 [0 - 65535] Shows the signal states from the active digital
*
3.15.4 18-7* Rectifier Status
This parameter group contains read-only parameters
related to the rectifier section.
126
Function:
terminal X42/7 on the analog I/O card.
The value shown reflects the selection in
parameter 26-40 Terminal X42/7 Output.
Function:
terminal X42/9 on the analog I/O card.
The value shown reflects the selection in
parameter 26-50 Terminal X42/9 Output.
Function:
terminal X42/11 on the analog I/O card.
The value shown reflects the selection in
parameter 26-60 Terminal X42/11 Output.
[0 - 999999 AirPresTo-
*
FlowUnit]
Function:
inputs.
•
0 = No signal.
•
1 = Connected signal.
Danfoss A/S © 05/2016 All rights reserved.
®
VLT Refrigeration Drive FC 103
18-70 Mains Voltage
Shows the mains line-to-line voltage measurements. The values
are RMS.
Array values:
•
•
•
•
Range:
0 V
*
18-71 Mains Frequency
Shows the mains frequency.
Range:
0 Hz
*
18-72 Mains Imbalance
Shows the maximum measured imbalance for the 3 mains line-
to-line measurements.
Range:
0 %
*
18-75 Rectifier DC Volt.
Shows the DC voltage measurement from the rectifier module.
Function:
Range:
0 V
*
0: Average.
1: Phase R to S.
2: Phase S to T.
3: Phase T to R.
Function:
[0 - 1000 V]
[-100 - 100 Hz]
[0 - 100 %]
[0 - 10000 V]
Function:
Function:
Function:
MG16H202
