Parameter Description
3.21.4 26-3* Analog Input X42/5
26-30 Terminal X42/5 Low Voltage
Range:
0.07 V [ 0 - par.
*
3 3
6-31 V]
26-31 Terminal X42/5 High Voltage
Range:
10 V [ par. 6-30
*
- 10 V]
26-34 Term. X42/5 Low Ref./Feedb. Value
Range:
0 [-999999.999 -
*
999999.999]
26-35 Term. X42/5 High Ref./Feedb. Value
Range:
100 [-999999.999 -
*
999999.999]
26-36 Term. X42/5 Filter Time Constant
Range:
0.001 s [0.001 - 10
*
s]
26-37 Term. X42/5 Live Zero
Option:
[0] Disabled
[1] Enabled
*
184
VLT
Function:
Enter the low voltage value. This analog
input scaling value should correspond to
the low reference/feedback value set in
parameter 26-34 Term. X42/5 Low Ref./Feedb.
Value.
Function:
Enter the high-voltage value. This analog
input scaling value should correspond to the
high reference/feedback value set in
parameter 26-35 Term. X42/5 High Ref./Feedb.
Value.
Function:
Enter the analog input scaling value that
corresponds to the low-voltage value set
in parameter 26-30 Terminal X42/5 Low
Voltage.
Function:
Enter the analog input scaling value
that corresponds to the high-voltage
value set in parameter 26-21 Terminal
X42/3 High Voltage.
Function:
NOTICE
This parameter cannot be adjusted
while the motor is running.
This is a first-order digital low-pass filter
time constant for suppressing noise in
terminal X42/5. A high time constant
value improves dampening, but also
increases the time delay through the
filter.
Function:
Enable or disable the live zero monitoring.
Danfoss A/S © 05/2016 All rights reserved.
®
Refrigeration Drive FC 103
3.21.5 26-4* Analog Input X42/7
26-40 Terminal X42/7 Output
Option:
[0] No operation
*
[100] Output
frequency
[101] Reference
[102] Feedback
[103] Motor Current
[104] Torque rel to
limit
[105] Torq relate to
rated
[106] Power
[107] Speed
[108] Torque
[109] Max Out Freq
[113] Ext. Closed
Loop 1
[114] Ext. Closed
Loop 2
[115] Ext. Closed
Loop 3
[121] Air pres. to
Flow
[139] Bus ctrl.
[141] Bus ctrl t.o.
26-41 Terminal X42/7 Min. Scale
Range:
0 % [0 -
*
200 %]
Function:
Set the function of terminal X42/7 as an
analog current output.
0–100 Hz, (0–10 V).
Minimum reference–maximum reference,
(0–10 V).
-200% to +200% of
parameter 3-03 Maximum Reference, (0–10
V).
0–inverter maximum current
(parameter 16-37 Inv. Max. Current), (0–10
V).
0–torque limit (parameter 4-16 Torque
Limit Motor Mode), (0–10 V).
0–motor rated torque, (0–10 V).
0–motor rated power, (0–10 V).
0–speed high limit (parameter 4-13 Motor
Speed High Limit [RPM] and
parameter 4-14 Motor Speed High Limit
[Hz]), (0–10 V).
0–100%, (0–10 V).
0–100%, (0–10 V).
0–100%, (0–10 V).
0–100%, (0–10 V).
0–100%, (0–10 V).
Function:
Scale the minimum output of the selected analog
signal at terminal X42/7, as a percentage of the
maximum signal level, example, if 0 V (or 0 Hz) is
required at 25% of the maximum output value,
program 25%. Scaling values up to 100% can
never be higher than the corresponding setting in
parameter 26-42 Terminal X42/7 Max. Scale.
See principle graph for parameter 6-51 Terminal 42
Output Min Scale.
