Parameter Description
The below setting options are all related to the pack
controller. Wiring diagrams and settings for parameter, see
parameter group 25-** Pack Controller for more details.
[120] Lead
3 3
Compressor
Start
[121] Lead
Compressor
Alternation
[130 Compressor
- 1 Interlock -
132] Compressor
3 Interlock
[139] Compressor
1 Inverse
Interlock
68
®
VLT Refrigeration Drive FC 103
Starts or stops the lead compressor
controlled by the frequency converter. A
start requires that a system start signal is
applied, for example to 1 of the digital
inputs set for [8] Start.
Forces alternation of the lead compressor in
a pack controller. Set parameter 25-50 Lead
Pump Alternation to either [2] At Command
or [3] At Staging or At Command. Set
parameter 25-51 Alternation Event to any
option.
Set parameter 25-90 Compressor Interlock to
[1] On. The option depends on the setting
in parameter 25-06 Number of Compressors.
If this option is set to [0] No, compressor 1
refers to the compressor controlled by relay
1, and so on. If this option is set to [1] Yes,
compressor 1 refers to the compressor
controlled by the frequency converter only
(without any of the built-in relays involved)
and compressor 2 refers to the compressor
controlled by relay 1. Variable speed
compressor (lead) cannot be interlocked.
Setting in Setting in
parameter parameter 25-06 Number of
group 5-1* Compressors
Digital Inputs
[0] No
[130] Controlled Controlled
Compressor 1 by relay 1
Interlock (only if not frequency
lead converter
compressor) (cannot be
interlocked)
[131] Controlled Controlled
Compressor2 by relay 2 by relay 1
Interlock
[132] Controlled Controlled
Compressor3 by relay 3 by relay 2
Interlock
Table 3.10 Compressor 1 Interlock -
Compressor 3 Interlock
Interlocks compressor 1 from the pack
controller when the signal is low and issues
warning 219, Compressor Interlock. When
inversely interlocked, compressor 1 (the
lead compressor) is staged according to
parameter 25-23 Fixed Speed neutral Zone
[unit].
Danfoss A/S © 05/2016 All rights reserved.
[140] Compressor
2 Inverse
Interlock
[141] Compressor
3 Inverse
Interlock
5-10 Terminal 18 Digital Input
The parameter contains all options and functions listed in
parameter group 5-1* Digital Inputs.
5-11 Terminal 19 Digital Input
The parameter contains all options and functions listed in
parameter group 5-1* Digital Inputs.
5-12 Terminal 27 Digital Input
The parameter contains all options and functions listed in
parameter group 5-1* Digital Inputs.
5-13 Terminal 29 Digital Input
The parameter contains all options and functions listed in
parameter group 5-1* Digital Inputs. This parameter also contains
options [60] Counter A (up), [61] Counter A (down), [63] Counter B
(up), and [64] Counter B (down) for smart logic control.
5-14 Terminal 32 Digital Input
The parameter contains all options and functions listed in
parameter group 5-1* Digital Inputs. This parameter also contains
options [60] Counter A (up), [61] Counter A (down), [63] Counter B
(up), and [64] Counter B (down) for smart logic control.
5-15 Terminal 33 Digital Input
The parameter contains all options and functions listed in
[1] Yes
parameter group 5-1* Digital Inputs. This parameter also contains
options [60] Counter A (up), [61] Counter A (down), [63] Counter B
by the
(up), and [64] Counter B (down) for smart logic control.
5-16 Terminal X30/2 Digital Input
This parameter is active when VLT
is installed in the frequency converter. The parameter contains all
options and functions listed in parameter group 5-1* Digital
Inputs.
5-17 Terminal X30/3 Digital Input
This parameter is active when VLT
is installed in the frequency converter. The parameter contains all
options and functions listed in parameter group 5-1* Digital
Inputs.
5-18 Terminal X30/4 Digital Input
This parameter is active when VLT
is installed in the frequency converter. The parameter contains all
options and functions listed in parameter group 5-1* Digital
Inputs.
Interlocks compressor 2 from the pack
controller when the signal is low and issues
warning 219, Compressor Interlock.
Interlocks compressor 3 from the pack
controller when the signal is low and issues
warning 219, Compressor Interlock.
®
General Purpose I/O MCB 101
®
General Purpose I/O MCB 101
®
General Purpose I/O MCB 101
