Parameter Description
13-01 Start Event
Option:
[45] Left Key
[46] Right Key
3 3
[47] Up Key
[48] Down Key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
13-02 Stop Event
Option:
[0] False
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current Limit
[7] Out of current
range
[8] Below I low
[9] Above I high
[10] Out of speed
range
[11] Below speed low
[12] Above speed high See parameter group 5-3* Digital Outputs
[13] Out of feedb.
range
96
®
VLT Refrigeration Drive FC 103
Function:
This event is true if [◄] is pressed.
This event is true if [►] is pressed.
▲
This event is true if [ ] is pressed.
▼
This event is true if [ ] is pressed.
Use the result of comparator 4 in the
logic rule.
Use the result of comparator 5 in the
logic rule.
Use the result of logic rule 4 in the logic
rule.
Use the result of logic rule 5 in the logic
rule.
Function:
Select the boolean (true or false) input
to deactivate smart logic control.
Enters the fixed value of false in the
logic rule.
Enters the fixed value true in the logic
rule.
See parameter group 5-3* Digital Outputs
for further description.
See parameter group 5-3* Digital Outputs
for further description.
See parameter group 5-3* Digital Outputs
for further description.
See parameter group 5-3* Digital Outputs
for further description.
See parameter group 5-3* Digital Outputs
for further description.
See parameter group 5-3* Digital Outputs
for further description.
See parameter group 5-3* Digital Outputs
for further description.
See parameter group 5-3* Digital Outputs
for further description.
See parameter group 5-3* Digital Outputs
for further description.
for further description.
See parameter group 5-3* Digital Outputs
for further description.
Danfoss A/S © 05/2016 All rights reserved.
13-02 Stop Event
Option: Function:
[14] Below feedb. low See parameter group 5-3* Digital Outputs
for further description.
[15] Above feedb. See parameter group 5-3* Digital Outputs
high for further description.
[16] Thermal warning See parameter group 5-3* Digital Outputs
for further description.
[17] Mains out of See parameter group 5-3* Digital Outputs
range for further description.
[18] Reversing See parameter group 5-3* Digital Outputs
for further description.
[19] Warning See parameter group 5-3* Digital Outputs
for further description.
[20] Alarm (trip) See parameter group 5-3* Digital Outputs
for further description.
[21] Alarm (trip lock) See parameter group 5-3* Digital Outputs
for further description.
[22] Comparator 0 Use the result of comparator 0 in the
logic rule.
[23] Comparator 1 Use the result of comparator 1 in the
logic rule.
[24] Comparator 2 Use the result of comparator 2 in the
logic rule.
[25] Comparator 3 Use the result of comparator 3 in the
logic rule.
[26] Logic rule 0 Use the result of logic rule 0 in the logic
rule.
[27] Logic rule 1 Use the result of logic rule 1 in the logic
rule.
[28] Logic rule 2 Use the result of logic rule 2 in the logic
rule.
[29] Logic rule 3 Use the result of logic rule 3 in the logic
rule.
[30] SL Time-out 0 Use the result of timer 0 in the logic
rule.
[31] SL Time-out 1 Use the result of timer 1 in the logic
rule.
[32] SL Time-out 2 Use the result of timer 2 in the logic
rule.
[33] Digital input DI18 Use the value of DI 18 in the logic rule
(High = true).
[34] Digital input DI19 Use the value of DI 19 in the logic rule
(High = true).
[35] Digital input DI27 Use the value of DI 27 in the logic rule
(High = true).
[36] Digital input DI29 Use the value of DI 29 in the logic rule
(High = true).
