Danfoss VLT Refrigeration Drive FC 103 Programming Manual page 29

Parameter Description
0-12 This Set-up Linked to
Option: Function:
0 RPM
Set-up Handling
0-12 This Set-up Linked to
Illustration 3.1 Set-up Handling
•
While still in set-up 1, using
parameter 0-50 LCP Copy, copy set-up
1 to set-up 2. Then set
parameter 0-12 This Set-up Linked to to
[2] Set-up 2. This starts the linking
process.
0 RPM
Set-up Handling
0-12 This Set-up Linked to
[2] Setup 2
Illustration 3.2 Set-up Handling
After the link is complete,
parameter 0-13 Readout: Linked Set-ups reads
set-ups 1 and 2 to indicate that all not
changeable during operation parameters are now
the same in set-up 1 and set-up 2. If there are
changes to a not changeable during operation
parameter in set-up 2, for example
parameter 1-30 Stator Resistance (Rs), they are
also changed automatically in set-up 1. A
switch between set-up 1 and set-up 2 during
operation is now possible.
[0] Not linked
*
[1] Set-up 1
[2] Set-up 2
[3] Set-up 3
[4] Set-up 4
0-13 Readout: Linked Set-ups
Array [5]
Range: Function:
0 [0 - View a list of all the set-ups linked by
*
255] parameter 0-12 This Set-up Linked to. The parameter
has 1 index for each parameter set-up. The value
for each index shows which set-ups are linked to
that parameter set-up.
MG16H202
Programming Guide
0-13 Readout: Linked Set-ups
Array [5]
Range:
0.00A 1(1)
0-1*
0-14 Readout: Prog. Set-ups / Channel
Range:
0
*
0.00A 1(1)
0-1*
3.2.2 0-2* LCP Display
Define the variables shown in the LCP.
NOTICE
For information on how to write display texts, refer to:
0-20 Display Line 1.1 Small
Option:
[37]
[38]
Danfoss A/S © 05/2016 All rights reserved.
Function:
Index LCP value
0 {0}
1 {1,2}
2 {1,2}
3 {3}
4 {4}
Table 3.1 Set-up Link Example
Function:
[-2147483648 View the setting of
- 2147483647] parameter 0-11 Programming Set-up for each
of the 4 different communication channels.
When the number is shown in hex, as it is in
the LCP, each number shows 1 channel.
Numbers 1–4 show a set-up number; F
stands for the factory setting, and A stands
for an active set-up. The channels are, from
right to left: LCP, fieldbus, USB, HPFB1.5.
Example: The value AAAAAA21h means that
the fieldbus channel uses set-up 2 in
parameter 0-11 Programming Set-up, the LCP
uses set-up 1, and all other channels use the
active set-up.
•
Parameter 0-37 Display Text 1.
•
Parameter 0-38 Display Text 2.
•
Parameter 0-39 Display Text 3.
Function:
Select a variable for display in line 1,
left position.
Display Text 1 Enables an individual text string to be
written for display in the LCP, or to be
read via serial communication.
Display Text 2 Enables an individual text string to be
written for display in the LCP, or to be
read via serial communication.
3 3
27
