Parameter Description
13-10 Comparator Operand
Array [5]
Option:
[65] Torque limit
[66] Current Limit
3 3
[67] Out of current range
[68] Below I low
[69] Above I high
[70] Out of speed range
[71] Below speed low
[72] Above speed high
[75] Out of feedback range
[76] Below feedback low
[77] Above feedback high
[80] Thermal warning
[82] Mains out of range
[85] Warning
[86] Alarm (trip)
[87] Alarm (trip lock)
[90] Bus OK
[91] Torque limit & stop
[92] Brake fault (IGBT)
[93] Mech. brake control
[94] Safe stop active
[100] Comparator 0
[101] Comparator 1
[102] Comparator 2
[103] Comparator 3
[104] Comparator 4
[105] Comparator 5
[110] Logic rule 0
[111] Logic rule 1
[112] Logic rule 2
[113] Logic rule 3
[114] Logic rule 4
[115] Logic rule 5
[120] SL Time-out 0
[121] SL Time-out 1
[122] SL Time-out 2
[123] SL Time-out 3
[124] SL Time-out 4
[125] SL Time-out 5
[126] SL Time-out 6
[127] SL Time-out 7
[130] Digital input DI18
[131] Digital input DI19
[132] Digital input DI27
[133] Digital input DI29
[134] Digital input DI32
[135] Digital input DI33
[150] SL digital output A
[151] SL digital output B
[152] SL digital output C
[153] SL digital output D
98
®
VLT Refrigeration Drive FC 103
Function:
Danfoss A/S © 05/2016 All rights reserved.
13-10 Comparator Operand
Array [5]
Option:
[154] SL digital output E
[155] SL digital output F
[160] Relay 1
[161] Relay 2
[180] Local referecnce active
[181] Remote reference active
[182] Start command
[183] Drive stopped
[185] Drive in hand mode
[186] Drive in auto mode
[187] Start command given
[190] Digital input x30/2
[191] Digital input x30/3
[192] Digital input x30/4
[205] No Flow
[206] Dry Pump
[207] End of Curve
[208] Broken Belt
13-11 Comparator Operator
Array [6]
Option: Function:
[0] < Select [0] < for the result of the evaluation to be
true, when the variable selected in
parameter 13-10 Comparator Operand is smaller
than the fixed value in
parameter 13-12 Comparator Value. The result is
false, if the variable selected in
parameter 13-10 Comparator Operand is greater
than the fixed value in
parameter 13-12 Comparator Value.
[1] ≈ (equal) Select [1] ≈ for the result of the evaluation to be
true, when the variable selected in
parameter 13-10 Comparator Operand is approxi-
mately equal to the fixed value in
parameter 13-12 Comparator Value.
[2] > Select [2] > for the inverse logic of option [0] <.
[5] TRUE
longer
than..
[6] FALSE
longer
than..
[7] TRUE
shorter
than..
[8] FALSE
shorter
than..
Function:
