Parameter Descriptions
8-49 BTM Error Log
Range: Function:
decimal break is the error code (255
means no error).
3.10.5 8-5* Digital/Bus
Parameters for configuring the control word Digital/Bus
merging.
NOTICE
These parameters are active only when 8-01 Control
Site is set to [0] Digital and control word.
8-50 Coasting Select
Option: Function:
Select control of the coasting function via the
terminals (digital input) and/or via the bus.
[0] Digital Activates Start command via a digital input.
input
[1] Bus Activates Start command via the serial communi-
cation port or fieldbus option.
[2] Logic Activates Start command via the fieldbus/serial
AND communication port, AND additionally via one of
the digital inputs.
[3] Logic OR Activates Start command via the fieldbus/serial
communication port OR via one of the digital
inputs.
8-51 Quick Stop Select
Select control of the Quick Stop function via the terminals
(digital input) and/or via the bus.
Option:
[0] Digital input
[1] Bus
[2] Logic AND
[3] Logic OR
*
8-52 DC Brake Select
Option: Function:
Select control of the DC brake via the terminals
(digital input) and/or via the fieldbus.
NOTICE
Only selection [0] Digital input is available
when 1-10 Motor Construction is set to [1]
PM non-salient SPM.
[0] Digital Activates Start command via a digital input.
input
®
VLT AutomationDrive FC 301/302 Programming Guide
8-53 Start Select
Option:
[0] Digital
input
[1] Bus
[2] Logic
AND
[3] Logic OR
8-54 Reversing Select
Option:
[0] Digital
input
[1] Bus
[2] Logic
AND
[3] Logic OR
*
8-55 Set-up Select
Option:
Function:
[0] Digital
input
[1] Bus
[2] Logic
AND
[3] Logic OR
8-56 Preset Reference Select
Option:
MG33MH02 - Rev. 2013-09-30
Function:
Select control of the frequency converter start
function via the terminals (digital input) and/or
via the fieldbus.
Activates Start command via a digital input.
Activates Start command via the serial communi-
cation port or fieldbus option.
Activates Start command via the fieldbus/serial
communication port, AND additionally via one of
the digital inputs.
Activates Start command via the fieldbus/serial
communication port OR via one of the digital
inputs.
Function:
Select control of the frequency converter
reverse function via the terminals (digital input)
and/or via the fieldbus.
Activates the Reverse command via the serial
communication port or fieldbus option.
Activates the Reverse command via the
fieldbus/serial communication port, AND
additionally via one of the digital inputs.
Activates the Reverse command via the
fieldbus/serial communication port OR via one
of the digital inputs.
Function:
Select control of the frequency converter set-up
selection via the terminals (digital input) and/or
via the fieldbus.
Activates the set-up selection via a digital input.
Activates the set-up selection via the serial
communication port or fieldbus option.
Activates the set-up selection via the fieldbus/
serial communication port, AND additionally via
one of the digital inputs.
Activate the set-up selection via the fieldbus/serial
communication port OR via one of the digital
inputs.
Function:
Select control of the frequency converter Preset
Reference selection via the terminals (digital
input) and/or via the fieldbus.
