Parameter Descriptions
17-50 Poles
Range: Function:
2 [2 - 8 ] Set the number of poles on the resolver.
*
The value is stated in the data sheet for resolvers.
17-51 Input Voltage
Range: Function:
7 V [2 - 8 V] Set the input voltage to the resolver. The
*
voltage is stated as RMS value.
The value is stated in the data sheet for
resolvers
17-52 Input Frequency
Range: Function:
10 kHz [2 - 15 Set the input frequency to the resolver.
*
kHz] The value is stated in the data sheet for
resolvers.
17-53 Transformation Ratio
Range: Function:
0.5 [0.1 - Set the transformation ratio for the resolver.
*
1.1 ] The transformation ration is:
V Out
T ratio =
V In
The value is stated in the data sheet for
resolvers.
17-56 Encoder Sim. Resolution
Set the resolution and activate the encoder emulation function
(generation of encoder signals from the measured position from
a resolver). Needed when necessary to transfer the speed or
position information from one drive to another. To disable the
function, select [0] Disabled.
Option:
[0]
*
[1]
[2]
[3]
[4]
17-59 Resolver Interface
Activate the MCB 103 resolver option when the resolver
parameters are selected.
To avoid damage to resolvers 17-50 Poles – 17-53 Transformation
Ratio must be adjusted before activating this parameter.
Option:
[0]
*
[1]
®
VLT AutomationDrive FC 301/302 Programming Guide
Function:
Disabled
512
1024
2048
4096
Function:
Disabled
Enabled
MG33MH02 - Rev. 2013-09-30
3.18.4 17-6* Monitoring and Application
This parameter group is for selecting additional functions
when Encoder option MCB 102 or Resolver Option MCB
103 is fitted into option slot B as speed feedback.
Monitoring and Application parameters cannot be adjusted
while the motor is running.
17-60 Feedback Direction
Option: Function:
NOTICE
This parameter cannot be adjusted
while the motor is running.
Change the detected encoder rotation
direction without changing the wiring to the
encoder.
[0] Clockwise
*
[1] Counter
clockwise
17-61 Feedback Signal Monitoring
Select which reaction the frequency converter should take in
case a faulty encoder signal is detected.
The encoder function in 17-61 Feedback Signal Monitoring is an
electrical check of the hardware circuit in the encoder system.
Option:
[0] Disabled
[1] Warning
*
[2] Trip
[3] Jog
[4] Freeze Output
[5] Max Speed
[6] Switch to Open Loop
[7] Select Setup 1
[8] Select Setup 2
[9] Select Setup 3
[10] Select Setup 4
[11] stop & trip
3 3
Function:
153
