Parameter Descriptions
6-62 Terminal X30/8 Max. Scale
Range: Function:
output. Scale the output to give a lower current
than 20 mA at full scale or 20 mA at an output
below 100% of the maximum signal value. If 20
mA is the desired output current at a value
between 0 - 100% of the ful-scale output, program
the percentage value in the parameter, i.e. 50% =
20 mA. If a current between 4 and 20 mA is
desired at maximum output (100%), calculate the
percentage value as follows:
20 mA / desired maximum current x 100 %
20 − 4
i . e . 10 mA : x 100 = 160 %
10
6-63 Terminal X30/8 Bus Control
Range: Function:
0 % [0 - 100 %] Holds the level of Output X30/8 if controlled
*
by bus.
6-64 Terminal X30/8 Output Timeout Preset
Range: Function:
0 % [0 - 100 Holds the preset level of Output X30/8.
*
%] In case of a bus timeout and a timeout function
is selected in 6-60 Terminal X30/8 Output, the
output is preset to this level.
3.8.8 6-7* Analog Output 3 MCB 113
Parameters for configuring the scaling and limits for
analog output 3, Terminal X45/1 and X45/2. Analog
outputs are current outputs: 0/4–20 mA. Resolution on
analog output is 11 bit.
6-70 Terminal X45/1 Output
Option: Function:
Select the function of Terminal X45/1 as an
analog current output.
[0] No When no signal on the analog output.
operation
[52] MCO 305
0-20 mA
[53] MCO 305
4-20 mA
[100] Output 0 Hz = 0 mA; 100 Hz = 20 mA.
frequency
0-20 mA
[101] Reference 3-00 Reference Range [Min - Max] 0% = 0
0-20 mA mA; 100% = 20 mA
3-00 Reference Range [-Max - Max] -100% = 0
mA; 0% = 10 mA; +100% = 20 mA
[102] Feedback
[103] Motor Value is taken from 16-37 Inv. Max. Current.
current 0-20 Inverter max. current (160% current) is equal
mA to 20 mA.
®
VLT AutomationDrive FC 301/302 Programming Guide
6-70 Terminal X45/1 Output
Option:
[104] Torque rel
to lim 0-20
mA
[105] Torque rel
to rated
motor
torque 0-20
mA
[106] Power 0-20
mA
[107] Speed 0-20
mA
[108] Torque ref.
0-20 mA
[109] Max Out
Freq 0-20
mA
[130] Output freq.
4-20 mA
[131] Reference
4-20 mA
[132] Feedback
4-20 mA
[133] Motor cur.
4-20 mA
[134] Torque%
lim. 4-20 mA
[135] Torque%
nom 4-20
mA
[136] Power 4-20
mA
MG33MH02 - Rev. 2013-09-30
Function:
Example: Inverter norm current (11 kW) = 24
A. 160% = 38.4 A. Motor norm current = 22
A Read-out 11.46 mA.
mA x 22 A
20
mA
= 11.46
38.4 A
In case the norm motor current is equal to
20 mA, the output setting of 6-52 Terminal
42 Output Max Scale is:
I VLT x 100
Max 38.4 x 100
= = 175 %
I Motor 22
Norm
The torque setting is related to setting in
4-16 Torque Limit Motor Mode
The torque is related to the motor torque
setting.
Taken from 1-20 Motor Power [kW].
Taken from 3-03 Maximum Reference. 20 mA
= value in 3-03 Maximum Reference
Torque reference related to 160% torque.
In relation to 4-19 Max Output Frequency.
0 Hz = 4 mA, 100 Hz = 20 mA
3-00 Reference Range [Min-Max] 0% = 4 mA;
100% = 20 mA
3-00 Reference Range [-Max-Max] -100% = 4
mA; 0% = 12 mA; +100% = 20 mA
Value is taken from 16-37 Inv. Max. Current.
Inverter max. current (160% current) is equal
to 20 mA.
Example: Inverter norm current (11 kW) = 24
A. 160% = 38.4 A. Motor norm current = 22
A Read-out 11.46 mA.
mA x 22 A
16
mA
= 9.17
38.4 A
In case the norm motor current is equal to
20 mA, the output setting of 6-52 Terminal
42 Output Max Scale is:
I VLT x 100
Max 38.4 x 100
= = 175 %
I Motor 22
Norm
The torque setting is related to setting in
4-16 Torque Limit Motor Mode.
The torque setting is related to the motor
torque setting.
Taken from 1-20 Motor Power [kW]
