Parameter Lists
Par. No. # Parameter description
Min Speed Normal Magnetising
1-52 [Hz]
1-53 Model Shift Frequency
Voltage reduction in
1-54 fieldweakening
1-55 U/f Characteristic - U
1-56 U/f Characteristic - F
1-58 Flystart Test Pulses Current
1-59 Flystart Test Pulses Frequency
1-6* Load Depen. Setting
1-60 Low Speed Load Compensation
1-61 High Speed Load Compensation
1-62 Slip Compensation
1-63 Slip Compensation Time Constant
1-64 Resonance Damping
Resonance Damping Time
1-65 Constant
1-66 Min. Current at Low Speed
1-67 Load Type
1-68 Minimum Inertia
1-69 Maximum Inertia
1-7* Start Adjustments
1-70 PM Start Mode
1-71 Start Delay
1-72 Start Function
1-73 Flying Start
1-74 Start Speed [RPM]
1-75 Start Speed [Hz]
1-76 Start Current
1-8* Stop Adjustments
1-80 Function at Stop
Min Speed for Function at Stop
1-81 [RPM]
Min Speed for Function at Stop
1-82 [Hz]
1-83 Precise Stop Function
1-84 Precise Stop Counter Value
Precise Stop Speed Compensation
1-85 Delay
1-9* Motor Temperature
1-90 Motor Thermal Protection
1-91 Motor External Fan
1-93 Thermistor Resource
1-94 ATEX ETR cur.lim. speed reduction
1-95 KTY Sensor Type
1-96 KTY Thermistor Resource
1-97 KTY Threshold level
1-98 ATEX ETR interpol. points freq.
1-99 ATEX ETR interpol points current
®
VLT AutomationDrive FC 301/302 Programming Guide
Default value 4-set-up
ExpressionLimit All set-ups
ExpressionLimit All set-ups
0 V All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
100 % All set-ups
100 % All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
100 % All set-ups
5 ms All set-ups
ExpressionLimit All set-ups
[0] Passive load All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
[0] Rotor Detection All set-ups
0 s All set-ups
[2] Coast/delay time All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
0 A All set-ups
[0] Coast All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
[0] Precise ramp stop All set-ups
100000 N/A All set-ups
10 ms All set-ups
[0] No protection All set-ups
ExpressionLimit All set-ups
[0] None All set-ups
0 % 2 set-ups
[0] KTY Sensor 1 All set-ups
[0] None All set-ups
80 °C 1 set-up
ExpressionLimit 1 set-up
ExpressionLimit 2 set-ups
