Parameter Descriptions
13-40 Logic Rule Boolean 1
Array [6]
Option:
[43] Ok key
[44] Reset key
[45] Left key
[46] Right key
[47] Up key
[48] Down key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[75] Start command given
[76] Digital input x30/2
[77] Digital input x30/3
[78] Digital input x30/4
[79] Digital input x46/1
[80] Digital input x46/3
[81] Digital input x46/5
[82] Digital input x46/7
[83] Digital input x46/9
[84] Digital input x46/11
[85] Digital input x46/13
[90] ATEX ETR cur. warning
[91] ATEX ETR cur. alarm
[92] ATEX ETR freq. warning Selectable, if 1-90 Motor Thermal
[93] ATEX ETR freq. alarm
[94] RS Flipflop 0
[95] RS Flipflop 1
[96] RS Flipflop 2
®
VLT AutomationDrive FC 301/302 Programming Guide
Function:
Selectable, if 1-90 Motor Thermal
Protection is set to [20] ATEX ETR
or [21] Advanced ETR. If the alarm
164 ATEX ETR cur.lim.alarm is
active, the output is 1.
Selectable, if1-90 Motor Thermal
Protection is set to [20] ATEX ETR
or [21] Advanced ETR. If the alarm
166 ATEX ETR freq.lim.alarm is
active, the output is 1.
Protection is set to [20] ATEX ETR
or [21] Advanced ETR. If the alarm
163 ATEX ETR cur.lim.warning is
active, the output is 1.
Selectable, if 1-90 Motor Thermal
Protection is set to [20] ATEX ETR
or [21] Advanced ETR. If the
warning 165 ATEX ETR
freq.lim.warning is active, the
output is 1.
See 13-1* Comparators
See 13-1* Comparators
See 13-1* Comparators
MG33MH02 - Rev. 2013-09-30
13-40 Logic Rule Boolean 1
Array [6]
Option: Function:
[97] RS Flipflop 3 See 13-1* Comparators
[98] RS Flipflop 4 See 13-1* Comparators
[99] RS Flipflop 5 See 13-1* Comparators
[100] RS Flipflop 6 See 13-1* Comparators
[101] RS Flipflop 7 See 13-1* Comparators
13-41 Logic Rule Operator 1
Array [6]
Option: Function:
Select the first logical operator to use on the
Boolean inputs from 13-40 Logic Rule Boolean
1 and 13-42 Logic Rule Boolean 2.
[13-**] signifies the boolean input of
parameter group 13-** Smart Logic Control.
[0] DISABLED Ignores 13-42 Logic Rule Boolean 2,
13-43 Logic Rule Operator 2, and 13-44 Logic
Rule Boolean 3.
[1] AND Evaluates the expression [13-40] AND [13-42].
[2] OR Evaluates the expression [13-40] OR [13-42].
[3] AND NOT Evaluates the expression [13-40] AND NOT
[13-42].
[4] OR NOT Evaluates the expression [13-40] OR NOT
[13-42].
[5] NOT AND Evaluates the expression NOT [13-40] AND
[13-42].
[6] NOT OR Evaluates the expression NOT [13-40] OR
[13-42].
[7] NOT AND NOT Evaluates the expression NOT [13-40] AND
NOT [13-42].
[8] NOT OR NOT Evaluates the expression NOT [13-40] OR
NOT [13-42].
13-42 Logic Rule Boolean 2
Array [6]
Option: Function:
[0] False Select the second boolean (TRUE
or FALSE) input for the selected
logic rule. See 13-01 Start Event
([0] - [61]) and 13-02 Stop Event
([70] - [75]) for further description.
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current Limit
[7] Out of current range
3 3
