Parameter Descriptions
8-41 Parameters for Signals
Option:
[1836] Analog Input X48/2 [mA]
[1837] Temp. Input X48/4
[1838] Temp. Input X48/7
3 3
[1839] Temp. Input X48/10
[1860] Digital Input 2
[3310] Sync Factor Master
[3311] Sync Factor Slave
[3401] PCD 1 Write to MCO
[3402] PCD 2 Write to MCO
[3403] PCD 3 Write to MCO
[3404] PCD 4 Write to MCO
[3405] PCD 5 Write to MCO
[3406] PCD 6 Write to MCO
[3407] PCD 7 Write to MCO
[3408] PCD 8 Write to MCO
[3409] PCD 9 Write to MCO
[3410] PCD 10 Write to MCO
[3421] PCD 1 Read from MCO
[3422] PCD 2 Read from MCO
[3423] PCD 3 Read from MCO
[3424] PCD 4 Read from MCO
[3425] PCD 5 Read from MCO
[3426] PCD 6 Read from MCO
[3427] PCD 7 Read from MCO
[3428] PCD 8 Read from MCO
[3429] PCD 9 Read from MCO
[3430] PCD 10 Read from MCO
[3440] Digital Inputs
[3441] Digital Outputs
[3450] Actual Position
[3451] Commanded Position
[3452] Actual Master Position
[3453] Slave Index Position
[3454] Master Index Position
[3455] Curve Position
[3456] Track Error
[3457] Synchronizing Error
[3458] Actual Velocity
[3459] Actual Master Velocity
[3460] Synchronizing Status
[3461] Axis Status
[3462] Program Status
[3464] MCO 302 Status
[3465] MCO 302 Control
[3470] MCO Alarm Word 1
[3471] MCO Alarm Word 2
[4280] Safe Option Status
[4285] Active Safe Func.
112
®
VLT AutomationDrive FC 301/302 Programming Guide
Function:
Size related
Size related
[0]
[1]
[2]
[3]
[0]
[1]
[2]
[3]
[4]
[5]
[6]
60 s
21
0.255
MG33MH02 - Rev. 2013-09-30
8-42 PCD Write Configuration
Range: Function:
[0 - Select the parameters to be assigned to
9999 ] PCD's telegrams. The number of available
PCDs depends on the telegram type. The
values in PCD's is then written to the
selected parameters as data values.
8-43 PCD Read Configuration
Range: Function:
[0 - Select the parameters to be assigned to
9999 ] PCD's of the telegrams. The number of
available PCDs depends on the telegram
type. PCDs contain the actual data
values of the selected parameters.
8-45 BTM Transaction Command
Option: Function:
NOTICE
This parameter cannot be
adjusted while the motor is
running.
Off
*
Start Transaction
Commit transaction
Clear error
8-46 BTM Transaction Status
Option:
Off
*
Transaction Started
Transaction Comitting
Transaction Timeout
Err. Non-existing Par.
Err. Par. Out of Range
Transaction Failed
8-47 BTM Timeout
Range: Function:
[1 - 360 s] Select the BTM Timeout after a BTM
*
transaction has been started.
8-48 BTM Maximum Errors
Range: Function:
[0 - 21 ] Selects the maximum allowed number of Bulk
*
Transfer Mode errors before aborting. If it is set
to maximum, there is no abort.
8-49 BTM Error Log
Range: Function:
[0.000 - List of parameters that failed during Bulk
*
9999.255 ] Transfer Mode. The value after the
Function:
