Parameter Descriptions
8-19 Product Code
Range:
Size related
*
2147483647 ]
3 3
3.10.3 8-3* FC Port Settings
8-30 Protocol
Option:
[0] FC
*
[1] FC MC
[2] Modbus RTU
8-31 Address
Range:
Size related
*
8-32 FC Port Baud Rate
Option:
[0] 2400 Baud
[1] 4800 Baud
[2] 9600 Baud
[3] 19200 Baud
[4] 38400 Baud
[5] 57600 Baud
[6] 76800 Baud
[7] 115200 Baud
8-33 Parity / Stop Bits
Option:
[0] Even Parity, 1 Stop Bit
*
[1] Odd Parity, 1 Stop Bit
[2] No Parity, 1 Stop Bit
[3] No Parity, 2 Stop Bits
8-34 Estimated cycle time
Range:
0 ms [0 -
*
1000000
ms]
110
Function:
[0 - Select [0] to readout the actual
fieldbus product code according
to the mounted fieldbus option.
Select [1] to readout the actual
Vendor ID.
Function:
Select the protocol to be used. Changing
protocol is not effective until after powering
off the frequency converter.
Function:
[ 1 - 255 ] Enter the address for the FC (standard)
port.
Valid range: 1-126.
Function:
Baud rate selection for the FC (standard) port.
Function:
In noisy environments, the interface may be
blocked due to overload or bad frames. This
parameter specifies the time between 2
consecutive frames on the network. If the
interface does not detect valid frames in
that time, it flushes the receive buffer.
®
VLT AutomationDrive FC 301/302 Programming Guide
8-35 Minimum Response Delay
Range:
10 ms
*
8-36 Max Response Delay
Range:
Size related
8-37 Max Inter-Char Delay
Range:
Size related
3.10.4 8-4* FC MC Protocol Set
8-40 Telegram Selection
Option:
[1] Standard telegram 1 Enables use of freely configurable
*
[100] None
[101] PPO 1
[102] PPO 2
[103] PPO 3
[104] PPO 4
Function:
[105] PPO 5
[106] PPO 6
[107] PPO 7
[108] PPO 8
[200] Custom telegram 1
[202] Custom telegram 3
8-41 Parameters for Signals
Option:
[0]
*
MG33MH02 - Rev. 2013-09-30
Function:
[ 1 - 10000 Specify the minimum delay time between
ms] receiving a request and transmitting a
response. This is used for overcoming
modem turnaround delays.
Function:
[ 11 - Specify the maximum permissible delay
*
10001 ms] time between transmitting a request
and receiving a response. If a response
from the frequency converter is
exceeding the time setting, then it is
discarded.
Function:
[ 0.00 - Specify the maximum permissible time
*
35.00 interval between receipt of 2 bytes. This
ms] parameter activates time-out if
transmission is interrupted.
This parameter is active only when
8-30 Protocol is set to [1] FC MC protocol.
Function:
telegrams or standard telegrams for
the FC port.
Enables use of freely configurable
telegrams or standard telegrams for
the FC port.
None This parameter contains a
list of signals available for
selection in 8-42 PCD
Write Configuration and
Function:
