Parameter Descriptions
14-55 Output Filter
Option: Function:
frequencies. Operation is possible with all control
principles. For FLUX control principle the parameters
14-56 Capacitance Output Filter and 14-57 Inductance
Output Filter have to be programmed (these
parameters have no effect in VVC
modulation pattern is set to SFAVM which gives the
lowest acoustic noise in the filter.
Note:
Reset the frequency converter after selecting [2]
Sine-Wafe Filter Fixed.
CAUTION
Always set 14-55 Output Filter to [2] Sine-
wave fixed when using a sine-wave filter.
Failure to do so can result in overheating of
the frequency converter, which can result in
personal injury and equipment damage.
14-56 Capacitance Output Filter
Compensation function of the LC-filter requires the per phase
equivalent star-connected capacitance of the filter (3 times the
capacity between 2 phases when capacitance is 'Delta'
connection).
Range: Function:
Size related [0.1 - Set the capacitance of the output filter.
*
6500 uF] The value can be found on the filter
label.
NOTICE
This is required for correct
compensation in Flux mode
(1-01 Motor Control Principle)
14-57 Inductance Output Filter
Range: Function:
Size related [0.001 - Set the inductance of the output filter.
*
65 mH] The value can be found on the filter
label.
NOTICE
This is required for correct
compensation in Flux mode
(1-01 Motor Control Principle)
14-59 Actual Number of Inverter Units
Range: Function:
Size related [ 1 - 1 ] Set the actual number of power units.
*
®
VLT AutomationDrive FC 301/302 Programming Guide
3.15.8 14-7* Compatibility
The parameters in this group are for setting of compati-
bility for VLT 3000, VLT 5000 to FC 300.
14-72 VLT Alarm Word
Option:
plus and U/f). The
[0] 0 - 4294967295 Read out the alarm word corresponding to
14-73 VLT Warning Word
Option:
[0] 0 - 4294967295 Read out the warning word corresponding
14-74 Leg. Ext. Status Word
Range:
0 [0 - 4294967295 ] Read out the ext. status word
*
3.15.9 14-8* Options
14-80 Option Supplied by External 24VDC
Option:
[0] No
[1] Yes Select [1] Yes if an external 24 V DC supply is used to
*
NOTICE
This parameter is only changing function
by performing a power cycle.
14-88 Option Data Storage
Range:
0 [0 - 65535 ] This parameter stores options data over a
*
14-89 Option Detection
Selects the behaviour of the frequency converter when a change
in the option configuration is detected.
Option:
[0] Protect
*
Option
Config.
[1] Enable
Option
Change
MG33MH02 - Rev. 2013-09-30
Function:
VLT 5000.
Function:
to VLT 5000.
Function:
corresponding to VLT 5000
Function:
Select [0] No to use the frequency converter's 24 V DC
supply.
power the option. Inputs/Outputs are galvanically
isolated from the frequency converter when operated
from an external supply.
Function:
power cycle.
Function:
Freezes the current settings and prevents
unwanted changes when missing or defective
options are detected.
Changes frequency converter settings and is
used when modifying the system configu-
ration. This parameter setting returns to [0]
Protect Option Config. after an Option Change.
3 3
