Danfoss VLT AutomationDrive FC 301 Programming Manual page 30

Parameter Descriptions
0-20 Display Line 1.1 Small
Option:
[1616] Torque [Nm]
[1617] Speed [RPM]
*
3 3
[1618] Motor Thermal
[1619] KTY sensor
temperature
[1620] Motor Angle
[1621] Torque [%] High Res.
[1622] Torque [%]
[1623] Motor Shaft Power
[kW]
[1624] Calibrated Stator
Resistance
[1625] Torque [Nm] High
[1630] DC Link Voltage
[1632] Brake Energy /s
[1633] Brake Energy /2 min
[1634] Heatsink Temp.
[1635] Inverter Thermal
[1636] Inv. Nom. Current
[1637] Inv. Max. Current
[1638] SL Controller State
[1639] Control Card Temp.
[1645] Motor Phase U Current
[1646] Motor Phase V Current
[1647] Motor Phase W Current
28
®
VLT AutomationDrive FC 301/302 Programming Guide
Function:
Actual motor torque in Nm
Speed in RPM (revolutions per
minute) i.e. the motor shaft
speed in closed loop.
Thermal load on the motor,
calculated by the ETR function.
Present motor load as a
percentage of the rated motor
torque.
Intermediate circuit voltage in
the frequency converter.
Present brake power
transferred to an external brake
resistor.
Stated as an instantaneous
value.
Brake power transferred to an
external brake resistor. The
mean power is calculated
continuously for the most
recent 120 s.
Present heat sink temperature
of the frequency converter. The
cut-out limit is 95 ±5 °C;
cutting back in occurs at 70 ±5
°C.
Percentage load of the
inverters.
Nominal current of the
frequency converter.
Maximum current of the
frequency converter.
State of the event executed by
the control.
Temperature of the control
card.
MG33MH02 - Rev. 2013-09-30
0-20 Display Line 1.1 Small
Option:
[1648] Speed Ref. After Ramp
[RPM]
[1650] External Reference
[1651] Pulse Reference
[1652] Feedback[Unit]
[1653] Digi Pot Reference
[1657] Feedback [RPM]
[1660] Digital Input
[1661] Terminal 53 Switch
Setting
[1662] Analog Input 53
[1663] Terminal 54 Switch
Setting
[1664] Analog Input 54
[1665] Analog Output 42
[mA]
[1666] Digital Output [bin]
[1667] Freq. Input #29 [Hz]
[1668] Freq. Input #33 [Hz]
[1669] Pulse Output #27 [Hz]
[1670] Pulse Output #29 [Hz]
[1671] Relay Output [bin]
Function:
Sum of the external reference
as a percentage, i.e. the sum of
analog/pulse/bus.
Frequency in Hz connected to
the digital inputs (18, 19 or 32,
33).
Reference value from
programmed digital input(s).
Signal states form the 6 digital
terminals (18, 19, 27, 29, 32
and 33). There are 16 bits in
total, but only six of them are
used. Input 18 corresponds to
the leftmost of the used bits.
Signal low = 0; Signal high = 1.
Setting of input terminal 54.
Current = 0; Voltage = 1.
Actual value at input 53 either
as a reference or protection
value.
Setting of input terminal 54.
Current = 0; Voltage = 1.
Actual value at input 54 either
as reference or protection
value.
Actual value at output 42 in
mA. Use 6-50 Terminal 42
Output to select the value to
be shown.
Binary value of all digital
outputs.
Actual value of the frequency
applied at terminal 29 as an
impulse input.
Actual value of the frequency
applied at terminal 33 as an
impulse input.
Actual value of impulses
applied to terminal 27 in
digital output mode.
Actual value of impulses
applied to terminal 29 in
digital output mode.
