Danfoss VLT AutomationDrive FC 301 Programming Manual page 100

Parameter Descriptions
6-60 Terminal X30/8 Output
Option:
[102] Feedback
3 3
[103] Motor
Current
[104] Torque rel
to limit
[105] Torq relate
to rated
[106] Power
[107] Speed
[108] Torque
[109] Max Out
Freq
[113] PID
Clamped
Output
[119] Torque %
lim
[130] Output
freq.
4-20mA
[131] Reference
4-20mA
[132] Feedback
4-20mA
[133] Motor cur.
4-20mA
98
®
VLT
Function:
3-00 Reference Range [-Max - Max] -100% = 0
mA; 0% = 10 mA; +100% = 20 mA
Value is taken from 16-37 Inv. Max. Current.
Inverter max. current (160% current) is equal
to 20 mA.
Example: Inverter norm current (11 kW) = 24
A. 160% = 38.4 A. Motor norm current = 22 A
Read-out 11.46 mA.
20 mA x 22 A
= 11.46 mA
A
38.4
In case the norm motor current is equal to 20
mA, the output setting of 6-62 Terminal X30/8
Max. Scale is:
I VLT x 100
Max 38.4 x 100
= = 175 %
I Motor 22
Norm
The torque setting is related to setting in
4-16 Torque Limit Motor Mode.
The torque is related to the motor torque
setting.
Taken from 1-20 Motor Power [kW].
Taken from 3-03 Maximum Reference. 20 mA
= value in 3-03 Maximum Reference
Torque reference related to 160% torque.
In relation to 4-19 Max Output Frequency.
0 Hz = 4 mA, 100 Hz = 20 mA
3-00 Reference Range [Min-Max] 0% = 4 mA;
100% = 20 mA
3-00 Reference Range [-Max-Max] -100% = 4
mA; 0% = 12 mA; +100% = 20 mA
Value is taken from 16-37 Inv. Max. Current.
Inverter max. current (160% current) is equal
to 20 mA.
Example: Inverter norm current (11 kW) = 24
A. 160% = 38.4 A. Motor norm current = 22 A
Read-out 11.46 mA.
mA x 22 A
16
mA
= 9.17
A
38.4
In case the norm motor current is equal to 20
mA, the output setting of 6-62 Terminal X30/8
Max. Scale is:
AutomationDrive FC 301/302 Programming Guide
6-60 Terminal X30/8 Output
Option:
[134] Torq.% lim
4-20 mA
[135] Torq.%
nom
4-20mA
[136] Power
4-20mA
[137] Speed
4-20mA
[138] Torque
4-20mA
[139] Bus ctrl.
0-20 mA
[140] Bus ctrl.
4-20 mA
[141] Bus ctrl
0-20mA t.o.
[142] Bus ctrl
4-20mA t.o.
[149] Torque %
lim 4-20mA
[150] Max Out Fr
4-20mA
6-61 Terminal X30/8 Min. Scale
Range:
0 % [0 -
*
200
%]
6-62 Terminal X30/8 Max. Scale
Range:
100 [0 -
% 200
*
%]
MG33MH02 - Rev. 2013-09-30
Function:
I VLT x 100
Max 38.4 x 100
= = 175 %
I Motor
22
Norm
The torque setting is related to setting in
4-16 Torque Limit Motor Mode.
The torque setting is related to the motor
torque setting.
Taken from 1-20 Motor Power [kW]
Taken from 3-03 Maximum Reference. 20 mA
= Value in 3-03 Maximum Reference.
Torque reference related to 160% torque.
An output value set from fieldbus process
data. The output works independently of
internal functions in the frequency converter.
An output value set from fieldbus process
data. The output works independently of
internal functions in the frequency converter.
4-54 Warning Reference Low defines the
behaviour of the analog output in case of
bus time-out.
4-54 Warning Reference Low defines the
behaviour of the analog output in case of
bus time-out.
Torque% Lim 4-20 mA: Torque reference.
3-00 Reference Range [Min-Max] 0% = 4 mA;
100% = 20 mA
3-00 Reference Range [-Max - Max] -100% = 4
mA; 0% = 12 mA; +100% = 20 mA
In relation to 4-19 Max Output Frequency.
Function:
Scales the minimum output of the selected analog
signal on terminal X30/8. Scale the minimum value
as a percentage of the maximum signal value, i.e. 0
mA (or 0 Hz) is desired at 25% of the maximum
output value and 25% is programmed. The value
can never be higher than the corresponding setting
in 6-62 Terminal X30/8 Max. Scale if value is below
100%.
This parameter is active when option module MCB
101 is mounted in the frequency converter.
Function:
Scales the maximum output of the selected
analog signal on terminal X30/8. Scale the value to
the desired maximum value of the current signal
