Parameter Descriptions
0-13 Readout: Linked Set-ups
Array [5]
Range: Function:
0 [0 - View a list of all the set-ups linked by means of
*
255 ] 0-12 This Set-up Linked to. The parameter has one
index for each parameter set-up. The parameter
value displayed for each index represents which set-
ups are linked to that parameter set-up.
Index LCP value
0 {0}
1 {1,2}
2 {1,2}
3 {3}
4 {4}
Table 3.2 Example: Set-up 1 and Set-up 2 are
linked
0-14 Readout: Edit Set-ups / Channel
Range: Function:
0 [-2147483648 View the setting of 0-11 Edit Set-up for each
*
- of the 4 different communication channels.
2147483647 ] When the number is displayed as a hex
number, as it is in the LCP, each number
represents one channel.
Numbers 1-4 represent a set-up number; 'F'
means factory setting; and 'A' means active
set-up. The channels are, from right to left:
LCP, FC-bus, USB, HPFB1-5.
Example: The number AAAAAA21h means
that the FC bus selected Set-up 2 in 0-11 Edit
Set-up, the LCP selected Set-up 1 and all
others used the active set-up.
0-15 Readout: actual setup
Range: Function:
0 [0 - 255 ] Makes it possible to read out the active set-up,
*
also when multi set-up is selected in 0-10 Active
Set-up.
3.2.3 0-2* LCP Display
Define the variables displayed in the Graphical Local
Control Panel.
NOTICE
Refer to 0-37 Display Text 1, 0-38 Display Text 2 and
0-39 Display Text 3 for information on how to write
display texts.
®
VLT AutomationDrive FC 301/302 Programming Guide
0-20 Display Line 1.1 Small
Option:
[0]
[9]
[15]
[37]
[38]
[39]
[748]
[953]
[1005]
[1006]
[1007]
[1013]
[1230]
[1472]
[1473]
[1474]
[1501]
[1502]
[1580]
[1600]
[1601]
[1602]
[1603]
[1605]
[1609]
[1610]
[1611]
[1612]
[1613]
[1614]
[1615]
MG33MH02 - Rev. 2013-09-30
Function:
Select a variable for display in
line 1, left position.
None No display value selected.
Performance Monitor
Readout: actual setup
Display Text 1
Display Text 2
Display Text 3
PCD Feed Forward
Profibus Warning Word
Readout Transmit Error
Counter
Readout Receive Error
Counter
Readout Bus Off
Counter
Warning Parameter
Warning Parameter
Legacy Alarm Word
Legacy Warning Word
Leg. Ext. Status Word
Running Hours
kWh Counter
Fan Running Hours
Control Word Present control word
Reference [Unit] Total reference (sum of digital/
analog/preset/bus/freeze ref./
catch up and slow-down) in
selected unit.
Reference % Total reference (sum of digital/
analog/preset/bus/freeze ref./
catch up and slow-down) in
percent.
Status Word Present status word.
Main Actual Value [%] Actual value as a percentage.
Custom Readout
Power [kW] Actual power consumed by the
motor in kW.
Power [hp] Actual power consumed by the
motor in hp.
Motor Voltage Voltage supplied to the motor.
Frequency Motor frequency, i.e. the
output frequency from the
frequency converter in Hz
Motor current Phase current of the motor
measured as effective value.
Frequency [%] Motor frequency, i.e. the
output frequency from the
frequency converter in percent.
3 3
