Parameter Descriptions
0-20 Display Line 1.1 Small
Option:
[1672] Counter A
[1673] Counter B
[1674] Prec. Stop Counter
[1675] Analog In X30/11
[1676] Analog In X30/12
[1677] Analog Out X30/8 [mA] Actual value at output X30/8 in
[1678] Analog Out X45/1 [mA]
[1679] Analog Out X45/3 [mA]
[1680] Fieldbus CTW 1
[1682] Fieldbus REF 1
[1684] Comm. Option STW
[1685] FC Port CTW 1
[1686] FC Port REF 1
[1687] Bus Readout Alarm/
Warning
[1690] Alarm Word
[1691] Alarm Word 2
[1692] Warning Word
[1693] Warning Word 2
[1694] Ext. Status Word
[1836] Analog Input X48/2
[mA]
[1837] Temp. Input X48/4
[1838] Temp. Input X48/7
[1839] Temp. Input X48/10
[1860] Digital Input 2
[1890] Process PID Error
®
VLT AutomationDrive FC 301/302 Programming Guide
Function:
Application dependent (e.g.
SLC Control)
Application dependent (e.g.
SLC Control)
Display the actual counter
value.
Actual value at input X30/11
either as reference or
protection value.
Actual value at input X30/12
either as reference or
protection value.
mA. Use 6-60 Terminal X30/8
Output to select the value to
be shown.
Control word (CTW) received
from the Bus Master.
Main reference value sent with
control word from the Bus
Master.
Extended fieldbus communi-
cation option status word.
Control word (CTW) received
from the Bus Master.
Status word (STW) sent to the
Bus Master.
One or more alarms in a Hex
code.
One or more alarms in a Hex
code.
One or more warnings in a Hex
code.
One or more warnings in a Hex
code.
One or more status conditions
in a Hex code.
MG33MH02 - Rev. 2013-09-30
0-20 Display Line 1.1 Small
Option:
[1891] Process PID Output
[1892] Process PID Clamped
Output
[1893] Process PID Gain
Scaled Output
[3019] Wobble Delta Freq.
Scaled
[3110] Bypass Status Word
[3111] Bypass Running Hours
[3401] PCD 1 Write to MCO
[3402] PCD 2 Write to MCO
[3403] PCD 3 Write to MCO
[3404] PCD 4 Write to MCO
[3405] PCD 5 Write to MCO
[3406] PCD 6 Write to MCO
[3407] PCD 7 Write to MCO
[3408] PCD 8 Write to MCO
[3409] PCD 9 Write to MCO
[3410] PCD 10 Write to MCO
[3421] PCD 1 Read from MCO
[3422] PCD 2 Read from MCO
[3423] PCD 3 Read from MCO
[3424] PCD 4 Read from MCO
[3425] PCD 5 Read from MCO
[3426] PCD 6 Read from MCO
[3427] PCD 7 Read from MCO
[3428] PCD 8 Read from MCO
[3429] PCD 9 Read from MCO
[3430] PCD 10 Read from
MCO
[3440] Digital Inputs
[3441] Digital Outputs
[3450] Actual Position
[3451] Commanded Position
[3452] Actual Master Position
[3453] Slave Index Position
[3454] Master Index Position
[3455] Curve Position
[3456] Track Error
[3457] Synchronizing Error
[3458] Actual Velocity
[3459] Actual Master Velocity
[3460] Synchronizing Status
[3461] Axis Status
[3462] Program Status
[3464] MCO 302 Status
[3465] MCO 302 Control
[3470] MCO Alarm Word 1
[3471] MCO Alarm Word 2
[4285] Active Safe Func.
[4286] Safe Option Info
[9913] Idle time
Function:
29
3 3
