Parameter Descriptions
13-52 SL Controller Action
Array [20]
Option:
[15] Select preset ref
5
3 3
[16] Select preset ref
6
[17] Select preset ref
7
[18] Select ramp 1
[19] Select ramp 2
[20] Select ramp 3
[21] Select ramp 4
[22] Run
[23] Run reverse
[24] Stop
[25] Qstop
[26] Dcstop
[27] Coast
[28] Freeze output
[29] Start timer 0
[30] Start timer 1
[31] Start timer 2
[32] Set digital out A
low
[33] Set digital out B
low
[34] Set digital out C
low
130
®
VLT AutomationDrive FC 301/302 Programming Guide
Function:
Selects preset reference 5.
If the active preset reference is changed,
it merges with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
Selects preset reference 6.
If the active preset reference is changed,
it merges with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
Selects preset reference 7.
If the active preset reference is changed,
it merges with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
Selects ramp 1.
Selects ramp 2.
Selects ramp 3.
Selects ramp 4.
Issues a start command to the frequency
converter.
Issues a start reverse command to the
frequency converter.
Issues a stop command to the frequency
converter.
Issues a quick stop command to the
frequency converter.
Issues a DC stop command to the
frequency converter.
The frequency converter coasts
immediately. All stop commands including
the coast command stop the SLC.
Freezes the output frequency of the
frequency converter.
Starts timer 0, see 13-20 SL Controller
Timer for further description.
Starts timer 1, see 13-20 SL Controller
Timer for further description.
Starts timer 2, see 13-20 SL Controller
Timer for further description.
Any output with SL output A is low.
Any output with SL output B is low.
Any output with SL output C is low.
MG33MH02 - Rev. 2013-09-30
13-52 SL Controller Action
Array [20]
Option: Function:
[35] Set digital out D Any output with SL output D is low.
low
[36] Set digital out E Any output with SL output E is low.
low
[37] Set digital out F Any output with SL output F is low.
low
[38] Set digital out A Any output with SL output A is high.
high
[39] Set digital out B Any output with SL output B is high.
high
[40] Set digital out C Any output with SL output C is high.
high
[41] Set digital out D Any output with SL output D is high.
high
[42] Set digital out E Any output with SL output E is high.
high
[43] Set digital out F Any output with SL output F is high.
high
[60] Reset Counter A Resets Counter A to zero.
[61] Reset Counter B Resets Counter B to zero.
[70] Start timer 3 Start Timer 3, see 13-20 SL Controller Timer
for further description.
[71] Start timer 4 Start Timer 4, see 13-20 SL Controller Timer
for further description.
[72] Start timer 5 Start Timer 5, see 13-20 SL Controller Timer
for further description.
[73] Start timer 6 Start Timer 6, see 13-20 SL Controller Timer
for further description.
[74] Start timer 7 Start Timer 7, see 13-20 SL Controller Timer
for further description.
