Parameter Descriptions
5-40 Function Relay
Array [9]
(Relay 1 [0], Relay 2 [1], Relay 3 [2] (MCB 113), Relay 4 [3] (MCB
113), Relay 5 [4] (MCB 113), Relay 6 [5] (MCB 113), Relay 7 [6]
(MCB 105), Relay 8 [7] (MCB 105), Relay 9 [8] (MCB 105))
Option:
Function:
[71]
Logic rule 1
See parameter group 13-4* Smart
Logic Control. If Logic Rule 1 in SLC is
TRUE, the output goes high.
Otherwise, it is low.
[72]
Logic rule 2
See parameter group 13-4* Smart
Logic Control. If Logic Rule 2 in SLC is
TRUE, the output goes high.
Otherwise, it is low.
[73]
Logic rule 3
See parameter group 13-4* Smart
Logic Control. If Logic Rule 3 in SLC is
TRUE, the output goes high.
Otherwise, it is low.
[74]
Logic rule 4
See parameter group 13-4* Smart
Logic Control. If Logic Rule 4 in SLC is
TRUE, the output goes high.
Otherwise, it is low.
[75]
Logic rule 5
See parameter group 13-4* Smart
Logic Control. If Logic Rule 5 in SLC is
TRUE, the output goes high.
Otherwise, it is low.
[80]
SL digital output A
See 13-52 SL Controller Action. Output
A is low on Smart Logic Action [32].
Output A is high on Smart Logic
Action [38].
[81]
SL digital output B
See 13-52 SL Controller Action. Output
B is low on Smart Logic Action [33].
Output B is high on Smart Logic
Action [39].
[82]
SL digital output C
See 13-52 SL Controller Action. Output
C is low on Smart Logic Action [34].
Output C is high on Smart Logic
Action [40].
[83]
SL digital output D
See 13-52 SL Controller Action. Output
D is low on Smart Logic Action [35].
Output D is high on Smart Logic
Action [41].
[84]
SL digital output E
See 13-52 SL Controller Action. Output
E is low on Smart Logic Action [36].
Output E is high on Smart Logic
Action [42].
[85]
SL digital output F
See 13-52 SL Controller Action. Output
F is low on Smart Logic Action [37].
Output F is high on Smart Logic
Action [43].
[120] Local ref active
Output is high when 3-13 Reference
Site = [2] Local or when
®
VLT
AutomationDrive FC 301/302 Programming Guide
5-40 Function Relay
Array [9]
(Relay 1 [0], Relay 2 [1], Relay 3 [2] (MCB 113), Relay 4 [3] (MCB
113), Relay 5 [4] (MCB 113), Relay 6 [5] (MCB 113), Relay 7 [6]
(MCB 105), Relay 8 [7] (MCB 105), Relay 9 [8] (MCB 105))
Option:
[121] Remote ref active
[122] No alarm
[123] Start command
activ
[124] Running reverse
[125] Drive in hand
mode
[126] Drive in auto mode Output is high when the frequency
MG33MH02 - Rev. 2013-09-30
Function:
3-13 Reference Site = [0] Linked to
hand auto at the same time as the
LCP is in Hand On mode.
Reference site
Local
Remote
set in
referen
reference
3-13 Reference
ce
active
Site
active
[121]
[120]
Reference site:
1
0
Local
3-13 Reference
Site [2]
Reference site:
0
1
Remote
3-13 Reference
Site [1]
Reference site:
Linked to Hand/
Auto
Hand
1
0
Hand -> off
1
0
Auto -> off
0
0
Auto
0
1
Table 3.19 Local Reference Active
Output is high when 3-13 Reference
Site = [1] Remote or [0] Linked to
hand/auto while the LCP is in Auto
On mode. See above.
Output is high when no alarm is
present.
Output is high when the Start
command high (i.e. via digital input,
bus connection or [Hand On] or
[Auto On] ), and a Stop has been last
command.
Output is high when the frequency
converter is running counter
clockwise (the logical product of the
status bits 'running' AND 'reverse').
Output is high when the frequency
converter is in [Hand on] mode (as
indicated by the LED light above
[Hand on]).
converter is in 'Auto' mode (as
3
3
87
