Parameter Descriptions
[56] DigiPot
Decrease
[57] DigiPot Clear
3 3
[60] Counter A
[61] Counter A
[62] Reset
Counter A
[63] Counter B
[64] Counter B
[65] Reset
Counter B
[70] Mech. Brake
Feedback
[71] Mech. Brake
Feedback inv.
[72] PID error
inverse
[73] PID reset I-
part
[74] PID enable
[80] PTC Card 1
[91] Profidrive
OFF2
[92] Profidrive
OFF3
[98] Start edge
triggered
[100] Safe Option
Reset
78
®
VLT AutomationDrive FC 301/302 Programming Guide
DECREASE signal to the Digital Potenti-
ometer function described in parameter
group 3-9* Digital Pot. Meter
Clears the Digital Potentiometer reference
described in parameter group 3-9* Digital
Pot. Meter
(Terminal 29 or 33 only) Input for increment
counting in the SLC counter.
(Terminal 29 or 33 only) Input for
decrement counting in the SLC counter.
Input for reset of counter A.
(Terminal 29 or 33 only) Input for increment
counting in the SLC counter.
(Terminal 29 or 33 only) Input for
decrement counting in the SLC counter.
Input for reset of counter B.
Brake feedback for hoisting applications: Set
1-01 Motor Control Principle to [3] flux w/
motor feedback; set 1-72 Start Function to [6]
Hoist mech brake Ref.
Inverted brake feedback for hoisting
applications
When enabled, it inverts the resulting error
from the process PID controller. Available
only if "Configuration Mode" is set to
"Surface Winder", "Extended PID Speed OL"
or "Extended PID Speed CL".
When enabled, resets the I-part of the
Process PID controller. Equivalent to
7-40 Process PID I-part Reset. Available only
if "Configuration Mode" is set to "Surface
Winder", "Extended PID Speed OL" or
"Extended PID Speed CL".
When enabled, enables the extended
process PID controller. Equivalent to
7-50 Process PID Extended PID. Available only
if "Configuration Mode" is set "Extended PID
Speed OL" or "Extended PID Speed CL".
All Digital Inputs can be set to [80] PTC
Card 1. However, only one Digital Input
must be set to this choice.
The functionality is the same as the
according control word bit of the Profibus/
Profinet option.
The functionality is the same as the
according control word bit of the Profibus/
Profinet option.
Edge triggered start command. Keeps the
start command alive. It can be used for a
start push-button.
5-10 Terminal 18 Digital Input
Option: Function:
[8] Start Functions are described under parameter group 5-1*
*
Digital Inputs
5-11 Terminal 19 Digital Input
Option:
[10] Reversing Functions are described under parameter group
*
5-12 Terminal 27 Digital Input
Option:
[2] Coast inverse Functions are described under parameter
*
5-13 Terminal 29 Digital Input
Option: Function:
Select the function from the available digital input
range and the additional options [60], [61], [63] and
[64]. Counters are used in Smart Logic Control
functions.This parameter is available for FC 302 only.
[14] Jog Functions are described under parameter group 5-1*
*
Digital Inputs
5-14 Terminal 32 Digital Input
Option:
No operation Functions are described under 5-1* Digital Inputs
5-15 Terminal 33 Digital Input
Option:
[0] No
*
operation
5-16 Terminal X30/2 Digital Input
Option:
[0] No
*
operation
5-17 Terminal X30/3 Digital Input
Option:
[0] No
*
operation
MG33MH02 - Rev. 2013-09-30
Function:
5-1* Digital Inputs
Function:
group 5-1* Digital Inputs
Function:
Select the function from the available digital
input range.
Function:
Select the function from the available digital
input range and the additional options [60],
[61], [63] and [64]. Counters are used in Smart
Logic Control functions.
Functions are described under 5-1* Digital
Inputs
Function:
This parameter is active when option module
MCB 101 is installed in the frequency
converter. Functions are described under 5-1*
Digital Inputs
Function:
This parameter is active when option module
MCB 101 is installed in the frequency
converter. Functions are described under 5-1*
Digital Inputs
