Parameter Descriptions
Adjust starting torque in 1-66 Min. Current at Low Speed.
100% provides nominal torque as starting torque.
1-10 Motor Construction
Option: Function:
Select the motor design type.
[0] Asynchron For asynchronous motors.
*
[1] PM, non salient For salient or non-salient PM motors.
SPM PM motors are divided into 2 groups, with
either surface-mounted (non-salient) or
interior (salient) magnets.
[3] SynRM
1-11 Motor Model
Option: Function:
NOTICE
This parameter is FC 302 only.
Automatically sets the manufacturer's values
for the selected motor. If the default value
[1] is used, settings must be determined
manually, according to the choice in
1-10 Motor Construction.
[1] Std. Default motor model when [0]* Asynchron is
Asynchron selected in 1-10 Motor Construction. Enter
motor parameter manually.
[2] Std. PM, non Selectable when [1] PM, non salient SPM is
salient selected in 1-10 Motor Construction. Enter
motor parameter manually.
[10] Danfoss OGD Selectable when [1] PM, non salient SPM is
LA10 selected in 1-10 Motor Construction. Only
available for T4, T5 in 1.5-3 kW. Settings are
loaded automatically for this specific motor.
See Table 3.4 for details.
[11] Danfoss OGD
V206
1-14 Damping Gain
Range: Function:
140 [0 - The damping gain stabilises the PM machine to
% 250 run the PM machine smooth and stable. The
*
%] value of Damping gain controls the dynamic
performance of the PM machine. High damping
gain gives high dynamic performance and low
damping gain gives low dynamic performance.
The dynamic performance is related to the
machine data and load type. If the damping gain
is too high or low the control becomes unstable.
1-15 Low Speed Filter Time Const.
Range: Function:
Size related [0.01 - This time constant is used below 10%
*
20 s] rated speed. Obtain quick control
®
VLT AutomationDrive FC 301/302 Programming Guide
1-15 Low Speed Filter Time Const.
Range:
1-16 High Speed Filter Time Const.
Range:
Size related
1-17 Voltage filter time const.
Range:
Size related
1-18 Min. Current at No Load
Range:
0 %
*
3.3.4 1-2* Motor Data
This parameter group contains input data from the
nameplate on the connected motor.
NOTICE
Changing the value of these parameters
affects the setting of other parameters.
NOTICE
1-20 Motor Power [kW], 1-21 Motor Power [HP], 1-22 Motor
Voltage and 1-23 Motor Frequency have no effect when
1-10 Motor Construction = [1] PM, non salient SPM.
1-20 Motor Power [kW]
Range:
Size
related
*
MG33MH02 - Rev. 2013-09-30
Function:
through a short damping time constant.
However, if this value is too short, the
control gets unstable.
Function:
[0.01 - This time constant is used above 10%
*
20 s] rated speed. Obtain quick control
through a short damping time constant.
However, if this value is too short, the
control gets unstable.
Function:
[0.001 - Reduces the influence of high frequency
*
1 s] ripple and system resonance in the
calculation of supply voltage. Without
this filter, the ripples in the currents can
distort the calculated voltage and affect
the stability of the system.
Function:
[0 - 50 %] Adjust this parameter to achieve a smoother
motor operation.
Function:
NOTICE
[ 0.09 -
3000.00
This parameter cannot be adjusted
kW]
while the motor is running.
Enter the nominal motor power in kW
according to the motor nameplate data.
The default value corresponds to the
nominal rated output of the unit.
