Parameter Descriptions
16-36 Inv. Nom. Current
Range:
Size related
*
10000 A]
3 3
16-37 Inv. Max. Current
Range:
Size related
*
10000 A]
16-38 SL Controller State
Range:
0 [0 - 100 ] View the state of the event under execution by
*
16-39 Control Card Temp.
Range:
0 °C [0 - 100 °C] View the temperature on the control card,
*
16-40 Logging Buffer Full
Option: Function:
View whether the logging buffer is full (see parameter
group 15-1* Data Log Settings). The logging buffer is
never full when setting 15-13 Logging Mode to [0] Log
always.
[0] No
[1] Yes
16-41 Logging Buffer Full
Range:
0
*
16-45 Motor Phase U Current
Range:
0 A [0 - 10000
*
A]
16-46 Motor Phase V Current
Range:
0 A [0 - 10000
*
A]
148
Function:
[0.01 - View the inverter nominal current,
which must match the nameplate data
on the connected motor. The data are
used for calculation of torque, motor
protection, etc.
Function:
[0.01 - View the inverter maximum current,
which must match the nameplate data
on the connected motor. The data are
used for calculation of torque, motor
protection, etc.
Function:
the SL controller.
Function:
stated in °C
Function:
[0 - 0 ]
Function:
Displays the Motor Phase U
Facilitates monitoring of imbalance in the
motor currents, detection of weak motor
cables or imbalance in motor windings.
Function:
Displays the Motor Phase V
Facilitates monitoring of imbalance in the
motor currents, detection of weak motor
cables or imbalance in motor windings.
®
VLT AutomationDrive FC 301/302 Programming Guide
3.17.4 16-47 Motor Phase W Current
16-47 Motor Phase W Current
Range:
0 A
*
A]
16-48 Speed Ref. After Ramp [RPM]
Range:
0 RPM
*
16-49 Current Fault Source
Range:
0 [0 - 8 ] Value indicates source of current faults including
*
3.17.5 16-5* Ref. & Feedb.
16-50 External Reference
Range:
0 [-200 -
*
200 ]
16-51 Pulse Reference
Range:
0 [-200 -
*
200 ]
16-52 Feedback[Unit]
Range:
current.
RMS
0 ReferenceFeed-
backUnit
current.
RMS
MG33MH02 - Rev. 2013-09-30
Function:
[0 - 10000 Displays the Motor Phase W
Facilitates monitoring of imbalance in the
motor currents , detection of weak motor
cables or imbalance in motor windings.
Function:
[-30000 - This parameter specifies the reference
30000 RPM] given to the frequency converter after
the speed ramp.
Function:
short circuit, over current, and phase imbalance
(from left):
1-4 Inverter
5-8 Rectifier
0 No fault recorded
Function:
View the total reference, the sum of digital,
analog, preset, bus and freeze references, plus
catch-up and slow-down.
Function:
View the reference value from programmed
digital input(s). The readout can also reflect the
impulses from an incremental encoder.
[-999999.999 -
999999.999
*
ReferenceFeed-
backUnit]
current.
RMS
Function:
View the feedback unit
resulting from the
selection of unit and
scaling in 3-00 Reference
Range, 3-01 Reference/
Feedback Unit,
3-02 Minimum Reference
and 3-03 Maximum
Reference.
