Parameter Lists
Par. No. # Parameter description
34-60 Synchronizing Status
34-61 Axis Status
34-62 Program Status
34-64 MCO 302 Status
34-65 MCO 302 Control
4 4
34-7* Diagnosis readouts
34-70 MCO Alarm Word 1
34-71 MCO Alarm Word 2
4.1.26 35-** Sensor Input Option
Par. Parameter description
No. #
35-0* Temp. Input Mode
35-00 Term. X48/4 Temp. Unit
35-01 Term. X48/4 Input Type
35-02 Term. X48/7 Temp. Unit
35-03 Term. X48/7 Input Type
35-04 Term. X48/10 Temp. Unit
35-05 Term. X48/10 Input Type
35-06 Temperature Sensor Alarm Function
35-1* Temp. Input X48/4
35-14 Term. X48/4 Filter Time Constant
35-15 Term. X48/4 Temp. Monitor
35-16 Term. X48/4 Low Temp. Limit
35-17 Term. X48/4 High Temp. Limit
35-2* Temp. Input X48/7
35-24 Term. X48/7 Filter Time Constant
35-25 Term. X48/7 Temp. Monitor
35-26 Term. X48/7 Low Temp. Limit
35-27 Term. X48/7 High Temp. Limit
35-3* Temp. Input X48/10
35-34 Term. X48/10 Filter Time Constant
35-35 Term. X48/10 Temp. Monitor
35-36 Term. X48/10 Low Temp. Limit
35-37 Term. X48/10 High Temp. Limit
35-4* Analog Input X48/2
35-42 Term. X48/2 Low Current
35-43 Term. X48/2 High Current
35-44 Term. X48/2 Low Ref./Feedb. Value
35-45 Term. X48/2 High Ref./Feedb. Value
35-46 Term. X48/2 Filter Time Constant
194
®
VLT AutomationDrive FC 301/302 Programming Guide
Default value 4-set-up
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
Default value 4-set-up
[60] °C All set-ups
[0] Not Connected All set-ups
[60] °C All set-ups
[0] Not Connected All set-ups
[60] °C All set-ups
[0] Not Connected All set-ups
[5] Stop and trip All set-ups
0.001 s All set-ups
[0] Disabled All set-ups
App.Dependent All set-ups
App.Dependent All set-ups
0.001 s All set-ups
[0] Disabled All set-ups
App.Dependent All set-ups
App.Dependent All set-ups
0.001 s All set-ups
[0] Disabled All set-ups
App.Dependent All set-ups
App.Dependent All set-ups
4.00 mA All set-ups
20.00 mA All set-ups
0.000 N/A All set-ups
100.000 N/A All set-ups
0.001 s All set-ups
MG33MH02 - Rev. 2013-09-30
FC 302 Change Conver-
only during sion index
operation
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
FALSE 0
FALSE 0
FC 302 Change
only during
operation
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
Type
Int32
Int32
Int32
Uint16
Uint16
Uint32
Uint32
Conver- Type
sion
index
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
-3 Uint16
- Uint8
0 Int16
0 Int16
-3 Uint16
- Uint8
0 Int16
0 Int16
-3 Uint16
- Uint8
0 Int16
0 Int16
-5 Int16
-5 Int16
-3 Int32
-3 Int32
-3 Uint16
