Parameter Descriptions
15-10 Logging Source
Array [4]
Option:
[1657] Feedback [RPM]
[1660] Digital Input
3 3
[1662] Analog Input 53
[1664] Analog Input 54
[1665] Analog Output 42 [mA]
[1666] Digital Output [bin]
[1675] Analog In X30/11
[1676] Analog In X30/12
[1677] Analog Out X30/8 [mA]
[1690] Alarm Word
[1692] Warning Word
[1694] Ext. Status Word
[1860] Digital Input 2
[3110] Bypass Status Word
[3470] MCO Alarm Word 1
[3471] MCO Alarm Word 2
15-11 Logging Interval
Array [4]
Range:
Size related
*
0.000 ]
15-12 Trigger Event
Select the trigger event. When the trigger event occurs, a
window is applied to freeze the log. The log then retains a
specified percentage of samples before the occurrence of the
trigger event (15-14 Samples Before Trigger).
Option:
[0]
*
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[12]
[13]
[14]
[15]
[16]
[17]
[18]
[19]
[20]
142
Function:
Function:
[ 0.000 - Enter the interval in milliseconds
between each sampling of the
variables to be logged.
False
True
Running
In range
On reference
Torque limit
Current Limit
Out of current range
Below I low
Above I high
Out of speed range
Below speed low
Above speed high
Out of feedb. range
Below feedb. low
Above feedb. high
Thermal warning
Mains out of range
Reversing
Warning
Alarm (trip)
®
VLT AutomationDrive FC 301/302 Programming Guide
15-12 Trigger Event
Select the trigger event. When the trigger event occurs, a
window is applied to freeze the log. The log then retains a
specified percentage of samples before the occurrence of the
trigger event (15-14 Samples Before Trigger).
Option:
[21]
[22]
[23]
[24]
[25]
[26]
[27]
[28]
[29]
[33]
[34]
[35]
[36]
[37]
[38]
[50]
[51]
[60]
[61]
15-13 Logging Mode
Option:
[0] Log always
[1] Log once on
trigger
Function:
15-14 Samples Before Trigger
Range:
50 [0 -
*
100 ]
3.16.3 15-2* Historic Log
View up to 50 logged data items via the array parameters
in this parameter group. For all parameters in the group,
[0] is the most recent data and [49] the oldest data. Data is
logged every time an event occurs (not to be confused
with SLC events). Events in this context are defined as a
change in one of the following areas
1.
2.
3.
4.
MG33MH02 - Rev. 2013-09-30
Alarm (trip lock)
Comparator 0
Comparator 1
Comparator 2
Comparator 3
Logic rule 0
Logic rule 1
Logic rule 2
Logic rule 3
Digital input DI18
Digital input DI19
Digital input DI27
Digital input DI29
Digital input DI32
Digital input DI33
Comparator 4
Comparator 5
Logic rule 4
Logic rule 5
Function:
Select [0] Log always for continuous logging.
Select [1] Log once on trigger to conditionally
start and stop logging using 15-12 Trigger
Event and 15-14 Samples Before Trigger.
Function:
Enter the percentage of all samples prior to a
trigger event which are to be retained in the
log. See also 15-12 Trigger Event and
15-13 Logging Mode.
Digital input
Digital outputs (not monitored in this SW release)
Warning word
Alarm word
Function:
