Parameter Descriptions
16-86 FC Port REF 1
Range: Function:
0 [-200 - View the two-byte status word (STW) sent to the
*
200 ] Bus-Master. Interpretation of the status word
depends on the fieldbus option installed and the
control word profile selected in 8-10 Control
Profile.
16-87 Bus Readout Alarm/Warning
Range: Function:
0 [0 - Alarm and Warning numbers in hex as displayed
*
65535 ] in the Alarm log. The High byte contains the
Alarm, the Low byte the Warning. The Alarm
number is the first one that occurred after the
last reset.
3.17.8 16-9* Diagnosis Read-Outs
NOTICE
When using MCT 10 Set-up Software, the readout
parameters can only be read online, i.e. as the actual
status. This means that the status is not stored in the
MCT 10 Set-up Software file.
16-90 Alarm Word
Range: Function:
0 [0 - 4294967295 ] View the alarm word sent via the serial
*
communication port in hex code.
16-91 Alarm Word 2
Range: Function:
0 [0 - 4294967295 ] View the alarm word sent via the serial
*
communication port in hex code.
16-92 Warning Word
Range: Function:
0 [0 - 4294967295 ] View the warning word sent via the
*
serial communication port in hex code.
16-93 Warning Word 2
Range: Function:
0 [0 - 4294967295 ] View the warning word sent via the serial
*
communication port in hex code.
16-94 Ext. Status Word
Range: Function:
0 [0 - 4294967295 ] Returns the extended warning word sent
*
via the serial communication port in hex
code.
®
