Parameter Descriptions
13-51 SL Controller Event
Array [20]
Option:
[76] Digital input x30/2
[77] Digital input x30/3
[78] Digital input x30/4
[79] Digital input x46/1
[80] Digital input x46/3
[81] Digital input x46/5
[82] Digital input x46/7
[83] Digital input x46/9
[84] Digital input x46/11
[85] Digital input x46/13
[90] ATEX ETR cur. warning
[91] ATEX ETR cur. alarm
[92] ATEX ETR freq. warning Selectable, if 1-90 Motor Thermal
[93] ATEX ETR freq. alarm
[94] RS Flipflop 0
[95] RS Flipflop 1
[96] RS Flipflop 2
[97] RS Flipflop 3
[98] RS Flipflop 4
[99] RS Flipflop 5
[100] RS Flipflop 6
[101] RS Flipflop 7
13-52 SL Controller Action
Array [20]
Option: Function:
[0] DISABLED Select the action corresponding to the
SLC event. Actions are executed when the
corresponding event (defined in 13-51 SL
Controller Event) is evaluated as true. The
®
VLT AutomationDrive FC 301/302 Programming Guide
Function:
Selectable, if 1-90 Motor Thermal
Protection is set to [20] ATEX ETR
or [21] Advanced ETR. If the alarm
164 ATEX ETR cur.lim.alarm is
active, the output is 1.
Selectable, if 1-90 Motor Thermal
Protection is set to [20] ATEX ETR
or [21] Advanced ETR]. If the alarm
166 ATEX ETR freq.lim.alarm is
active, the output is 1.
Protection is set to [20] ATEX ETR
or [21] Advanced ETR. If the alarm
163 ATEX ETR cur.lim.warning is
active, the output is 1.
Selectable, if 1-90 Motor Thermal
Protection is set to [20] ATEX ETR
or [21] Advanced ETR. If the
warning 165 ATEX ETR
freq.lim.warning is active, the
output is 1.
See 13-1* Comparators
See 13-1* Comparators
See 13-1* Comparators
See 13-1* Comparators
See 13-1* Comparators
See 13-1* Comparators
See 13-1* Comparators
See 13-1* Comparators
MG33MH02 - Rev. 2013-09-30
13-52 SL Controller Action
Array [20]
Option: Function:
following actions are available for
selection:
[0] *DISABLED
[1] No action
[2] Select set-up 1 Changes the active set-up (0-10 Active Set-
up) to '1'.
If the set-up is changed, it merges with
other set-up commands coming from
either the digital inputs or via a fieldbus.
[3] Select set-up 2 Changes the active set-up 0-10 Active Set-
up) to '2'.
If the set-up is changed, it merges with
other set-up commands coming from
either the digital inputs or via a fieldbus.
[4] Select set-up 3 Changes the active set-up (0-10 Active Set-
up) to '3'.
If the set-up is changed, it merges with
other set-up commands coming from
either the digital inputs or via a fieldbus.
[5] Select set-up 4 Changes the active set-up (0-10 Active Set-
up) to '4'.
If the set-up is changed, it merges with
other set-up commands coming from
either the digital inputs or via a fieldbus.
[10] Select preset ref Selects preset reference 0.
0 If the active preset reference is changed,
it merges with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
[11] Select preset ref Selects preset reference 1.
1 If the active preset reference is changed,
it merges with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
[12] Select preset ref Selects preset reference 2.
2 If the active preset reference is changed,
it merges with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
[13] Select preset ref Selects preset reference 3.
3 If the active preset reference is changed,
it merges with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
[14] Select preset ref Selects preset reference 4.
4 If the active preset reference is changed,
it merges with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
