Parameter Descriptions
1-33 Stator Leakage Reactance (X1)
Range:
Size [ 0.0400 -
related 400.0000
*
Ohm]
3 3
NOTICE
1-33 Stator Leakage Reactance (X1)do not have effect
when 1-10 Motor Construction = [1] PM, non-salient SPM.
1-34 Rotor Leakage Reactance (X2)
Range:
Size [ 0.0400 -
related 400.0000
*
Ohm]
NOTICE
1-34 Rotor Leakage Reactance (X2)do not have effect
when 1-10 Motor Construction = [1] PM, non-salient SPM.
1-35 Main Reactance (Xh)
Range:
Size [ 1.0000 -
related 10000.0000
*
Ohm]
40
®
VLT AutomationDrive FC 301/302 Programming Guide
Function:
Set the stator leakage reactance of the
motor using one of these methods:
1. Run an AMA on a cold motor.
The frequency converter
measures the value from the
motor.
2. Enter the X value manually.
1
Obtain the value from the
motor supplier.
3. Use the X default setting. The
1
frequency converter establishes
the setting based on the motor
nameplate data.
See Illustration 3.6.
Function:
Set the rotor leakage reactance of the
motor using one of these methods:
1. Run an AMA on a cold motor.
The frequency converter
measures the value from the
motor.
2. Enter the X value manually.
2
Obtain the value from the
motor supplier.
3. Use the X default setting. The
2
frequency converter establishes
the setting based on the motor
nameplate data.
See Illustration 3.6.
Function:
Set the main reactance of the motor
using one of these methods:
1. Run an AMA on a cold motor.
The frequency converter
MG33MH02 - Rev. 2013-09-30
1-35 Main Reactance (Xh)
Range: Function:
2.
3.
1-36 Iron Loss Resistance (Rfe)
Range: Function:
Size [ 0 - Enter the equivalent iron loss
related 10000.000 resistance (R
*
Ohm] for iron loss in the motor.
The R
performing an AMA.
The R
in torque control applications. If R
unknown, leave 1-36 Iron Loss
Resistance (Rfe) on default setting.
1-37 d-axis Inductance (Ld)
Range: Function:
Size [0.0 - Enter line to common direct axis inductance
related 1000.0 of the PM motor. Obtain the value from the
*
mH] permanent magnet motor data sheet.
If only line-line data are available, divide the
line-line value by 2 to achieve the line-
common (starpoint) value. Alternatively
measure the value with an inductancemeter,
this also takes the inductance of the cable
into account. Divide the measured value by
2 and enter the result.
This parameter is only active when
1-10 Motor Construction has the value [1] PM,
non-salient SPM (Permanent Magnet Motor).
For a selection with one decimal, use this
parameter. For a selection with three
decimals, use 30-80 d-axis Inductance (Ld).
FC 302 only.
1-38 q-axis Inductance (Lq)
Range: Function:
Size related [0.000 - 1000 Set the value of the q-axis
*
mH] inductance. See themotor data
sheet.
1-39 Motor Poles
Range: Function:
Size related [2 - 128 ] Enter the number of motor poles.
*
measures the value from the
motor.
Enter the X value manually.
h
Obtain the value from the
motor supplier.
Use the X default setting. The
h
frequency converter
establishes the setting based
on the motor nameplate data.
) value to compensate
Fe
value cannot be found by
Fe
value is especially important
Fe
is
Fe
