Polycom SoundStructure C16 Design Manual page 340

Design Guide for the Polycom SoundStructure C16, C12, C8, and SR12
12 - 42
Control
Line Keys
Line Labels
Phone UI Messages
Phone soft keys
Audio Settings
Dial pad
Phone onhook/offhook
Dialed digits
Description
Shows all lines that have been defined with call
servers. Up to 12 lines can be shown here.
Lines 1-6 are shown on the left side of the
Phone UI messages area and Lines 7 - 12 are
shown in the right side of the Phone UI
messages area. If the line is registered, the
line icon will display as solid
or
if the line is not registered, the line icon will
display as an outline
The label associated with the particular line.
Shows any messages from the phone such as
showing the calling party information. This
area will behave similarly to the display in the
SoundPoint IP phones.
The keys displayed vary depending on the call
state and can be used to get a new line, end a
call, put a call on hold, resume a call, transfer a
call, and create conference calls.
The audio settings allow an integrator to
customize the in-room behavior of the
SoundStructure VoIP Interface with auto
answer, auto hangup, and ringtone selection.
The dial pad allows the integrator to dial digits
to make a call to test the system.
Indicates whether the call is offhook
(phone_connect = 1) or onhook
(phone_connect = 0).
Displays the dialed digits for the current call.
.
