Once the ungated signal is selected in the matrix, the decision of which
ungated type of the signal is used is made on the channels page on an input by
input basis.
As described in Chapter 2, there are four different types of ungated signal pro-
cessing paths that may be selected for each input. The different signal
processing paths for the four ungated signal types are summarized in the fol-
lowing table.
Ungated Type
Bypass
Line Input
Conferencing
Sound Reinforcement
The default ungated type depends on the type of input signal as shown in the
following table.
Signal Type
Microphone channels
Non microphone channels
Customizing SoundStructure Designs
Summary
No signal processing on the audio
channel.
Equalization, dynamics processing, AGC
Equalization, echo and noise cancellation,
non linear processing, dynamics
processing, AGC
Equalization, echo and noise cancellation,
feedback elimination, dynamics
processing, AGC
Default ungated type
Sound Reinforcement
Line input
5 - 23
