How to Program
Change the selected digit infinitely variably with [
The cursor indicates the selected digit. Place the cursor on
the digit to save and press [OK].
957RPM
Start Adjustments
1-71 High starting torque time
0. s
4
Illustration 2.20 Saving

2.1.14 Value, Step-by-step

Certain parameters can be changed step-by-step. This
applies to:
Parameter 1-20 Motor Power [kW].
Parameter 1-22 Motor Voltage.
Parameter 1-23 Motor Frequency.
The parameters are changed both as a group of numeric
data values and as numeric data values that are infinitely
varying.
2.1.15 Readout and Programming of
Indexed Parameters
Parameters are indexed when placed in a rolling stack.
Parameter 15-30 Fault Log: Error Code to
parameter 15-32 Alarm Log: Time contain a fault log, which
can be read out. Select a parameter, press [OK], and press
the keys [
] [
] to scroll through the value log.
For example, parameter 3-10 Preset Reference is changed as
follows:
1.
Select the parameter, press [OK], and press [
to scroll through the indexed values.
2.
To change the parameter value, select the
indexed value and press [OK].
3.
Change the value by pressing [
4.
Press [OK] to accept the new setting.
5.
Press [Cancel] to abort. Press [Back] to leave the
parameter.
2.1.16 How to Program on the Numerical
Local Control Panel
The following instructions are valid for the numerical LCP
(LCP 101).
The control panel is divided into 4 functional groups:
MG33ML02
Programming Guide
] [
].
11.58A
1 (1)
1-7*
Display line
Status messages showing icons and numeric value.
LCP keys
[Menu]
Select 1 of the following modes:
1
2
] [
]
] [
].
3
4
Danfoss A/S © 02/2016 All rights reserved.
1.
Numerical display.
2.
Menu keys and indicator lights - changing
parameters and switching between display
functions.
3.
Navigation keys and indicator lights.
4.
Operation keys and indicator lights.
Indicator lights
Green LED/On: Indicates if control section is on.
Yellow LED/Wrn: Indicates a warning.
Flashing red LED/Alarm: Indicates an alarm.
Status.
Quick Set-up.
Main Menu.
Status
Menu
OK
On
Warn.
Alarm
Hand
O
on
Illustration 2.21 LCP Keys
Setup
Quick
Main
Setup
Menu
Auto
Reset
on
25
2
2
