Parameter Descriptions
13-02 Stop Event
Select the boolean (true or false) input to deactivate smart logic
control.
Option:
[70] SL Time-out 3
3 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[75] Start command given
[76] Digital input x30/2
[77] Digital input x30/3
[78] Digital input x30/4
[79] Digital input x46/1
[80] Digital input x46/3
[81] Digital input x46/5
[82] Digital input x46/7
[83] Digital input x46/9
[84] Digital input x46/11
[85] Digital input x46/13
[90] ATEX ETR cur. warning Available, if parameter 1-90 Motor
[91] ATEX ETR cur. alarm
[92] ATEX ETR freq.
warning
[93] ATEX ETR freq. alarm
[94] RS Flipflop 0
[95] RS Flipflop 1
142
®
VLT AutomationDrive FC 301/302
Function:
Smart logic controller timer 3 is
timed out.
Smart logic controller timer 4 is
timed out.
Smart logic controller timer 5 is
timed out.
Smart logic controller timer 6 is
timed out.
Smart logic controller timer 7 is
timed out.
Thermal Protection is set to [20]
ATEX ETR or [21] Advanced ETR. If
the alarm 164, ATEX ETR
cur.lim.alarm is active, the output is
1.
Available, if parameter 1-90 Motor
Thermal Protection is set to [20]
ATEX ETR or [21] Advanced ETR. If
alarm 166, ATEX ETR freq.lim.alarm
is active, the output is 1.
Available, if parameter 1-90 Motor
Thermal Protection is set to [20]
ATEX ETR or [21] Advanced ETR. If
alarm 163, ATEX ETR cur.lim.warning
is active, the output is 1.
Available, if parameter 1-90 Motor
Thermal Protection is set to [20]
ATEX ETR or [21] Advanced ETR. If
warning 165, ATEX ETR
freq.lim.warning is active, the
output is 1.
See chapter 3.14.2 13-1*
Comparators.
See chapter 3.14.2 13-1*
Comparators.
Danfoss A/S © 02/2016 All rights reserved.
13-02 Stop Event
Select the boolean (true or false) input to deactivate smart logic
control.
Option: Function:
[96] RS Flipflop 2 See chapter 3.14.2 13-1*
Comparators.
[97] RS Flipflop 3 See chapter 3.14.2 13-1*
Comparators.
[98] RS Flipflop 4 See chapter 3.14.2 13-1*
Comparators.
[99] RS Flipflop 5 See chapter 3.14.2 13-1*
Comparators.
[100] RS Flipflop 6 See chapter 3.14.2 13-1*
Comparators.
[101] RS Flipflop 7 See chapter 3.14.2 13-1*
Comparators.
[102] Relay 1
[103] Relay 2
[104] Relay 3
X47/VLT
MCB 113
[105] Relay 4
X47/VLT
MCB 113
[106] Relay 5
X47/VLT
MCB 113
[107] Relay 6
X47/VLT
MCB 113
[108] Relay 7
X34/VLT
[109] Relay 8
X34/VLT
[110] Relay 9
X34/VLT
13-03 Reset SLC
Option: Function:
[0] Do not Retains programmed settings in
*
reset SLC chapter 3.14 Parameters: 13-** Smart Logic
Control.
[1] Reset SLC Resets all parameters in
chapter 3.14 Parameters: 13-** Smart Logic
Control to default settings.
®
Extended Relay Card
®
Extended Relay Card
®
Extended Relay Card
®
Extended Relay Card
®
Relay Card MCB 105
®
Relay Card MCB 105
®
Relay Card MCB 105
MG33ML02
