Another easy way of commissioning the frequency
converter is by using the smart application set-up (SAS),
which can also be found by pressing [Quick Menu]. Follow
the instructions on the successive shields to set up the
applications listed.
The [Info] key can be used throughout the SAS to see help
information for various selections, settings, and messages.
The following 3 applications are included:
•
Mechanical Brake.
•
Conveyor.
•
Pump/Fan.
The following 4 fieldbusses can be selected:
•
PROFIBUS.
•
PROFINET.
•
DeviceNet.
•
EtherNet/IP.
NOTICE
The frequency converter ignores the start conditions
when SAS is active.
NOTICE
The smart set-up runs automatically on the first power-
up of the frequency converter or after a reset to factory
settings. If no action is taken, the SAS shield automat-
ically disappears after 10 minutes.

2.1.8 Main Menu Mode

Press [Main Menu] to enter the main menu mode. The
readout in Illustration 2.14 appears on the display.
The middle and bottom sections in the display show a list
of parameter groups, which can be selected by toggling
▲ ▼
the [ ] and [ ] keys.
1107 RPM 3.84 A
Main Menu
0 - ** Operation/Display
1 - ** Load/Motor
2 - ** Brakes
3 - ** Reference / Ramps
Illustration 2.14 Main Menu Mode
MG33ML02
Programming Guide
Each parameter has a name and number which remain the
same regardless of the programming mode. In the main
menu mode, the parameters are divided into groups. The
first digit of the parameter number (from the left) indicates
the parameter group number.
All parameters can be changed in the Main Menu.
However, depending on the choice of configuration
(parameter 1-00 Configuration Mode), some parameters can
be hidden. For example, open loop hides all the PID
parameters, and other enabled options make more
parameter groups visible.

2.1.9 Parameter Selection

In the main menu mode, the parameters are divided into
groups. Select a parameter group with the navigation keys.
The following parameter groups are accessible:
Group
number
0-**
1-**
2-**
3-**
4-**
5-**
6-**
7-**
8-**
9-**
10-**
11-**
12-**
13-**
14-**
15-**
16-**
17-**
1 (1)
18-**
20-**
21-**
22-**
23-**
24-**
25-**
26-**
29-**
30-**
32-**
33-**
34-**
35-**
Table 2.4 Accessible Parameter Groups
