Parameter Descriptions
13-42 Logic Rule Boolean 2
Option:
[100] RS Flipflop 6
[101] RS Flipflop 7
3 3
[102] Relay 1
[103] Relay 2
[104] Relay 3
[105] Relay 4
[106] Relay 5
[107] Relay 6
[108] Relay 7
[109] Relay 8
[110] Relay 9
13-43 Logic Rule Operator 2
Array [6]
Option:
[0] DISABLED
[1] AND
[2] OR
[3] AND NOT
[4] OR NOT
[5] NOT AND
[6] NOT OR
[7] NOT AND
NOT
[8] NOT OR NOT
152
®
VLT
Function:
See chapter 3.14.2 13-1*
Comparators.
See chapter 3.14.2 13-1*
Comparators.
®
X47/VLT Extended Relay Card
MCB 113.
®
X47/VLT Extended Relay Card
MCB 113.
®
X47/VLT Extended Relay Card
MCB 113.
®
X47/VLT Extended Relay Card
MCB 113.
®
X34/VLT Relay Card MCB 105.
®
X34/VLT Relay Card MCB 105.
®
X34/VLT Relay Card MCB 105.
Function:
nd
Select the 2 logical operator to be used on
the boolean input calculated in:
•
Parameter 13-40 Logic Rule Boolean 1.
•
Parameter 13-41 Logic Rule Operator
1.
•
Parameter 13-42 Logic Rule Boolean 2.
and the boolean input coming from
parameter 13-42 Logic Rule Boolean 2.
[13-44] signifies the boolean input of
parameter 13-44 Logic Rule Boolean 3.
[13-40/13-42] signifies the boolean input
calculated in:
•
Parameter 13-40 Logic Rule Boolean 1.
•
Parameter 13-41 Logic Rule Operator
1.
•
Parameter 13-42 Logic Rule Boolean 2.
Select this option to ignore
parameter 13-44 Logic Rule Boolean 3.
Danfoss A/S © 02/2016 All rights reserved.
AutomationDrive FC 301/302
13-44 Logic Rule Boolean 3
Array [6]
Option:
[0] False
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current Limit
[7] Out of current range
[8] Below I low
[9] Above I high
[10] Out of speed range
[11] Below speed low
[12] Above speed high
[13] Out of feedb. range
[14] Below feedb. low
[15] Above feedb. high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[39] Start command
[40] Drive stopped
[41] Reset Trip
[42] Auto-reset Trip
Function:
Select the third boolean (true or
false) input for the selected logic
rule. See parameter 13-01 Start
Event (options [0] False–[61] Logic
rule 5) and parameter 13-02 Stop
Event (options [70] SL Time-out 3–
[75] Start command given) for more
information.
