Parameter Descriptions
3.10 Parameters: 8-** Communications and
Options
3.10.1 8-0* General Settings
8-01 Control Site
Option: Function:
The setting in this parameter overrides the
settings in parameter 8-50 Coasting Select to
parameter 8-56 Preset Reference Select.
[0] Digital and Control by using both digital input and
ctrl.word control word.
[1] Digital only Control by using digital inputs only.
[2] Controlword Control by using control word only.
only
8-02 Control Word Source
Option: Function:
NOTICE
This parameter cannot be adjusted
while the motor is running.
Select the source of the control word: 1 of 2
serial interfaces or 4 installed options. During
initial power-up, the frequency converter
automatically sets this parameter to [3] Option
A if it detects a valid fieldbus option installed
in slot A. When the option is removed, the
frequency converter detects a configuration
change, sets parameter 8-02 Control Word
Source to default setting [1] FC RS485, and
trips. If an option is installed after initial
power-up, the setting of
parameter 8-02 Control Word Source does not
change, but the frequency converter trips and
shows: Alarm 67, Option Changed.
When retrofitting a bus option into a
frequency converter that did not have a bus
option installed earlier, change the control to
bus-based. This change is required for safety
reasons to avoid an unintended change.
[0] None
[1] FC RS485
[2] FC USB
[3] Option A
[4] Option B
[5] Option C0
[6] Option C1
[30] External Can
MG33ML02
Programming Guide
8-03 Control Word Timeout Time
Range:
20 s
*
18000.0 s]
8-04 Control Word Timeout Function
Select the timeout function. The timeout function activates when
the control word fails to be updated within the time period
specified in parameter 8-03 Control Word Timeout Time.
Option:
[0] Off
[1] Freeze
output
[2] Stop
[3] Jogging
[4] Max. speed Runs the motor at maximum frequency until
[5] Stop and
trip
[7] Select
setup 1
[8] Select
setup 2
[9] Select
setup 3
[10] Select
setup 4
Danfoss A/S © 02/2016 All rights reserved.
Function:
[0.1 - Enter the maximum time expected to pass
between the reception of 2 consecutive
telegrams. If this time is exceeded, it indicates
that the serial communication has stopped.
The function selected in
parameter 8-04 Control Word Timeout Function
is then carried out. A valid control word
triggers the time-out counter.
Function:
NOTICE
To change the set-up after a timeout,
configure as follows:
1. Set parameter 0-10 Active Set-
up to [9] Multi set-up.
2. Select the relevant link in
parameter 0-12 This Set-up
Linked to.
Resumes control via fieldbus (fieldbus or
standard), using the most recent control word.
Freezes output frequency until communication
resumes.
Stops with auto restart when communication
resumes.
Runs the motor at jog frequency until
communication resumes.
communication resumes.
Stops the motor, then resets the frequency
converter to restart:
•
Via the fieldbus.
•
Via [Reset].
•
Via a digital input.
Changes the set-up after a control word
timeout. If communication resumes after a
timeout, parameter 8-05 End-of-Timeout
Function either resumes the set-up used before
the timeout, or retains the set-up endorsed by
the timeout function.
See [7] Select set-up 1.
See [7] Select set-up 1.
See [7] Select set-up 1.
