Parameter Lists
15-70 Option in Slot A
15-71 Slot A Option SW Version
15-72 Option in Slot B
15-73 Slot B Option SW Version
15-74 Option in Slot C0/E0
15-75 Slot C0/E0 Option SW Version
15-76 Option in Slot C1/E1
15-77 Slot C1/E1 Option SW Version
4 4
15-8* Operating Data II
15-80 Fan Running Hours
15-81 Preset Fan Running Hours
15-89 Configuration Change Counter
15-9* Parameter Info
15-92 Defined Parameters
15-93 Modified Parameters
15-98 Drive Identification
15-99 Parameter Metadata
4.1.19 16-** Data Readouts
Par- Parameter description
ameter #
16-0* General Status
16-00 Control Word
16-01 Reference [Unit]
16-02 Reference %
16-03 Status Word
16-05 Main Actual Value [%]
16-06 Actual Position
16-07 Target Position
16-08 Position Error
16-09 Custom Readout
16-1* Motor Status
16-10 Power [kW]
16-11 Power [hp]
16-12 Motor Voltage
16-13 Frequency
16-14 Motor current
16-15 Frequency [%]
16-16 Torque [Nm]
16-17 Speed [RPM]
16-18 Motor Thermal
16-19 KTY sensor temperature
16-20 Motor Angle
16-21 Torque [%] High Res.
16-22 Torque [%]
16-23 Motor Shaft Power [kW]
16-24 Calibrated Stator Resistance
16-25 Torque [Nm] High
222
®
VLT AutomationDrive FC 301/302
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 h All set-ups
0 h All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
Default value 4 set-up
0 N/A All set-ups
0 ReferenceFeed-
backUnit All set-ups
0 % All set-ups
0 N/A All set-ups
0 % All set-ups
0 CustomRea-
doutUnit2 All set-ups
0 CustomRea-
doutUnit2 All set-ups
0 CustomRea-
doutUnit2 All set-ups
0 CustomRea-
doutUnit All set-ups
0 kW All set-ups
0 hp All set-ups
0 V All set-ups
0 Hz All set-ups
0 A All set-ups
0 % All set-ups
0 Nm All set-ups
0 RPM All set-ups
0 % All set-ups
0 °C All set-ups
0 N/A All set-ups
0 % All set-ups
0 % All set-ups
0 kW All set-ups
0.0000 Ohm All set-ups
0 Nm All set-ups
