Parameter Descriptions
5-60 Terminal 27 Pulse Output Variable
Option:
[0] No operation
[45] Bus ctrl.
3 3
[48] Bus ctrl., timeout
[100] Output frequency
[101] Reference
[102] Feedback
[103] Motor Current
[104] Torque rel to limit
[105] Torq relate to rated
[106] Power
[107] Speed
[108] Torque
[109] Max Out Freq
[119] Torque % lim
5-62 Pulse Output Max Freq #27
Range:
Size
related Hz]
*
5-63 Terminal 29 Pulse Output Variable
Option:
[0] No operation
[45] Bus ctrl.
[48] Bus ctrl., timeout
[100] Output frequency
[101] Reference
[102] Feedback
[103] Motor Current
[104] Torque rel to limit
[105] Torq relate to rated
[106] Power
[107] Speed
[108] Torque
[109] Max Out Freq
[119] Torque % lim
108
Function:
Select the display output for terminal
27.
Function:
[0 - 32000 Set the maximum frequency for
terminal 27, corresponding to the
output variable selected in
parameter 5-60 Terminal 27 Pulse
Output Variable.
Function:
NOTICE
This parameter is available for
FC 302 only.
Select the display output for terminal
29.
Danfoss A/S © 02/2016 All rights reserved.
®
VLT AutomationDrive FC 301/302
5-65 Pulse Output Max Freq #29
Range:
5000 Hz
5-66 Terminal X30/6 Pulse Output Variable
Select the variable for readout on terminal X30/6.
This parameter is active when VLT
is installed in the frequency converter.
Same options and functions as parameter group 5-6* Pulse
Outputs.
Option:
[0]
[45]
[48]
[100]
[101]
[102]
[103]
[104]
[105]
[106]
[107]
[108]
[109]
[119]
5-68 Pulse Output Max Freq #X30/6
Range:
Size
related
*
3.7.7 5-7* 24 V Encoder Input
Connect the 24 V encoder to terminal 12 (24 V DC supply),
terminal 32 (channel A), terminal 33 (channel B), and
terminal 20 (GND). The digital inputs 32/33 are active for
encoder inputs when [1] 24 V encoder is selected in
parameter 1-02 Flux Motor Feedback Source and
parameter 7-00 Speed PID Feedback Source. The encoder
used is a dual-channel (A and B) 24 V type. Maximum
input frequency: 110 kHz.
Function:
[0 - 32000 Set the maximum frequency for terminal
*
Hz] 29 corresponding to the output variable
set in parameter 5-63 Terminal 29 Pulse
Output Variable.
®
General Purpose I/O MCB 101
No operation
Bus ctrl.
Bus ctrl., timeout
Output frequency
Reference
Feedback
Motor Current
Torque rel to limit
Torq relate to rated
Power
Speed
Torque
Max Out Freq
Torque % lim
Function:
NOTICE
[0 -
32000 Hz]
This parameter cannot be adjusted
while the motor is running.
Select the maximum frequency on
terminal X30/6 referring to the output
variable in parameter 5-66 Terminal X30/6
Pulse Output Variable.
This parameter is active when VLT
General Purpose I/O MCB 101 is installed
in the frequency converter.
Function:
®
