Parameter Lists
17-92 Position Control Selection
4.1.21 18-** Data Readouts 2
Par- Parameter description
ameter #
18-3* Analog Readouts
18-36 Analog Input X48/2 [mA]
18-37 Temp. Input X48/4
18-38 Temp. Input X48/7
18-39 Temp. Input X48/10
18-5* Active Alarms/Warnings
18-55 Active Alarm Numbers
18-56 Active Warning Numbers
18-6* Inputs & Outputs 2
18-60 Digital Input 2
4.1.22 30-** Special Features
Par- Parameter description
ameter #
30-2* Adv. Start Adjust
30-20 High Starting Torque Time [s]
30-21 High Starting Torque Current [%]
30-22 Locked Rotor Protection
30-23 Locked Rotor Detection Time [s]
Locked Rotor Detection Speed Error
30-24 [%]
30-25 Light Load Delay [s]
30-26 Light Load Current [%]
30-27 Light Load Speed [%]
30-8* Compatibility (I)
30-80 d-axis Inductance (Ld)
30-81 Brake Resistor (ohm)
30-83 Speed PID Proportional Gain
30-84 Process PID Proportional Gain
4.1.23 35-** Sensor Input Option
Par- Parameter description
ameter #
35-0* Temp. Input Mode
35-00 Term. X48/4 Temperature Unit
35-01 Term. X48/4 Input Type
35-02 Term. X48/7 Temperature Unit
35-03 Term. X48/7 Input Type
35-04 Term. X48/10 Temperature Unit
35-05 Term. X48/10 Input Type
35-06 Temperature Sensor Alarm Function
35-1* Temp. Input X48/4
35-14 Term. X48/4 Filter Time Constant
35-15 Term. X48/4 Temp. Monitor
35-16 Term. X48/4 Low Temp. Limit
MG33ML02
Programming Guide
[0] No operation All set-ups
Default value 4 set-up
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
Default value 4 set-up
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
25 % All set-ups
0.000 s All set-ups
0 % All set-ups
0 % All set-ups
ExpressionLimit All set-ups
ExpressionLimit 1 set-up
ExpressionLimit All set-ups
0.100 N/A All set-ups
Default value 4 set-up
[60] °C All set-ups
[0] Not Connected All set-ups
[60] °C All set-ups
[0] Not Connected All set-ups
[60] °C All set-ups
[0] Not Connected All set-ups
[5] Stop and trip All set-ups
0.001 s All set-ups
[0] Disabled All set-ups
ExpressionLimit All set-ups
Danfoss A/S © 02/2016 All rights reserved.
FALSE –
Change during Conversion
operation index
TRUE -3
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
FALSE 0
Change during Conversion
operation index
TRUE -2
TRUE -1
TRUE –
TRUE -2
TRUE -1
TRUE -3
TRUE 0
TRUE 0
FALSE -6
TRUE -2
TRUE -4
TRUE -3
Change during Conversion
operation index
TRUE –
TRUE –
TRUE –
TRUE –
TRUE –
TRUE –
TRUE –
TRUE -3
TRUE –
TRUE 0
uint8
Type
Int32
4 4
Int16
Int16
Int16
Uint16
Uint16
Uint16
Type
Uint16
Uint32
Uint8
Uint8
Uint32
Uint32
Uint16
Uint16
Int32
Uint32
Uint32
Uint16
Type
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint16
Uint8
Int16
225
