Parameter Descriptions
13-44 Logic Rule Boolean 3
Array [6]
Option:
[43] Ok key [OK] is pressed. Only available on
the graphical LCP.
[44] Reset key [Reset] is pressed. Only available
on the graphical LCP.
[45] Left key
[◄] is pressed. Only available on
the graphical LCP.
[46] Right key [►] is pressed. Only available on
the graphical LCP.
[47] Up key
[
the graphical LCP.
[48] Down key
[
the graphical LCP.
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[75] Start command given
[76] Digital input x30/2
[77] Digital input x30/3
[78] Digital input x30/4
[79] Digital input x46/1
[80] Digital input x46/3
[81] Digital input x46/5
[82] Digital input x46/7
[83] Digital input x46/9
[84] Digital input x46/11
[85] Digital input x46/13
[90] ATEX ETR cur. warning Available, if parameter 1-90 Motor
Thermal Protection is set to [20]
ATEX ETR or [21] Advanced ETR. If
alarm 164, ATEX ETR cur.lim.alarm is
active, the output is 1.
[91] ATEX ETR cur. alarm Available, if parameter 1-90 Motor
Thermal Protection is set to [20]
ATEX ETR or [21] Advanced ETR. If
alarm 166, ATEX ETR freq.lim.alarm
is active, the output is 1.
[92] ATEX ETR freq. Available, if parameter 1-90 Motor
warning Thermal Protection is set to [20]
ATEX ETR or [21] Advanced ETR. If
alarm 163, ATEX ETR cur.lim.warning
is active, the output is 1.
[93] ATEX ETR freq. alarm Available, if parameter 1-90 Motor
Thermal Protection is set to [20]
MG33ML02
Programming Guide
Function:
▲
] is pressed. Only available on
▼
] is pressed. Only available on
Danfoss A/S © 02/2016 All rights reserved.
13-44 Logic Rule Boolean 3
Array [6]
Option:
ATEX ETR or [21] Advanced ETR]. If
warning 165, ATEX ETR
freq.lim.warning is active, the
output is 1.
[94] RS Flipflop 0 See chapter 3.14.2 13-1*
Comparators.
[95] RS Flipflop 1 See chapter 3.14.2 13-1*
Comparators.
[96] RS Flipflop 2 See chapter 3.14.2 13-1*
Comparators.
[97] RS Flipflop 3 See chapter 3.14.2 13-1*
Comparators.
[98] RS Flipflop 4 See chapter 3.14.2 13-1*
Comparators.
[99] RS Flipflop 5 See chapter 3.14.2 13-1*
Comparators.
[100] RS Flipflop 6 See chapter 3.14.2 13-1*
Comparators.
[101] RS Flipflop 7 See chapter 3.14.2 13-1*
Comparators.
[102] Relay 1
[103] Relay 2
[104] Relay 3
X47/VLT
MCB 113.
[105] Relay 4
X47/VLT
MCB 113.
[106] Relay 5
X47/VLT
MCB 113.
[107] Relay 6
X47/VLT
MCB 113.
[108] Relay 7
X34/VLT
[109] Relay 8
X34/VLT
[110] Relay 9
X34/VLT
3.14.6 13-5* States
13-51 SL Controller Event
Option:
[0] False Select the boolean input (true or
false) to define the smart logic
controller event. See
parameter 13-01 Start Event
(options [0] False–[61] Logic rule 5)
and parameter 13-02 Stop Event
(options [70] SL Time-out 3–[74] SL
Time-out 7) for more information.
Function:
®
Extended Relay Card
®
Extended Relay Card
®
Extended Relay Card
®
Extended Relay Card
®
Relay Card MCB 105.
®
Relay Card MCB 105.
®
Relay Card MCB 105.
Function:
